# CalQlata's Technical Definitions

This page is provided as a list of definitions for all the technical terms used throughout this website. However, as it is also a useful technical dictionary, it is important that it is error-free. Therefore CalQlata would appreciate its users pointing out any such errors along with the corrected text and/or images. Thank you!

High definition values for all constants referred to in this definition page are provided in CalQlata's UniQon calculator.

 1-D (line) A one dimensional shape: a straight line 2-D (plane) A two dimensional shape: a planar or 'flat' shape that becomes invisible if viewed 'edge-on' 3-D (body) A three dimensional shape: a shape with volume and mass Acceleration (a) Rate of change in velocity. This value may be interpreted as the second derivative of the distance between two points in a journey, which may described mathematically thus: distance: s = u.t + ½.a.t² velocity: δs = u + a.t . δt acceleration: δ²s = a . δt² example units for which are; m/s² (metric) or ft/s² (Imperial). where: s = distance u = initial velocity t = elapsed time for 's' a = acceleration Acid A corrosive substance at the low end of the pᴴ scale (0<7) Acids turn blue litmus paper pink but do not affect pink litmus paper. The acidic component of water is H⁺. Mix acid with alkaline and the resultant substance tends towards neutral. Acute (angle) An angle between 0° and 90° Added Mass Coefficient(Ca or Cm) A coefficient that represents the additional mass of liquid or gas displaced by a body in which it is immersed: (0 < Ca < 1) 'additional' means the volume over and above that displaced by the body itself (C = 1.0) Whilst there are certain circumstances where an added mass coefficient can exceed 1.0, it is a rare occurrence that is invariably due to complex shapes see Added Drag-technical help see also Inertia Coefficient and Virtual Mass Adiabatic(thermodynamics) A process that generates a variation in the volume, pressure and/or temperature of a substance, but no heat is added to the system (from outside) or lost to its surroundings (from inside) Aerobe An organism that can only live in the presence of free oxygen Aerobic The breathing (respiration) of free oxygen and its conversion to energy In earth's animals this means the conversion of oxygen (together with other elements) into water and carbon-dioxide via glycolysis, oxidative decarboxylation and oxidative phosphorylation Age Hardening A hardening process that occurs with time with no added chemicals or energy see also Marageing Air (the Earth) The earth's atmosphere is divided into the following layers: Troposphere Stratosphere Mesosphere Ionosphere (lower Thermosphere) Exosphere (upper Thermosphere) 99.999622% of the Earth's air (atmosphere) comprises the following gases: Name (percentage) [ceiling @ equator & poles] {mass} Nitrogen (78.087%) [3999km & 3458.5km] {4.131E+18kg} Oxygen (20.95%) [3118km & 2666km] {1.108E+18kg} Argon (0.93%) [1985.5km & 1647.6km] {4.914E+16kg} Carbon Dioxide (0.03%) [1525.4km & 1236.4km] {1.585E+15kg} Neon (0.0018%) [n/a] {9.506E+13kg} Helium (0.00052%) [n/a] {2.746E+13kg} Hydrocarbons (0.0002%) [n/a] {1.056E+13kg} Hydrogen (0.000048%) [n/a] {2.535E+12kg} Nitrous Oxide (0.00005%) [n/a] {2.638E+12kg} Ozone (0.000004%) [991.6km & 776km] {n/a} to which must be added trace elements & about 2% Water Properties# @ sea level and 273.15K: Density; 1276.9153g/m³ excluding water 1292.8g/m³ including 2% water Pressure; 101324.618N/m² excluding water 103351.118N/m² including 2% water RAM; 28.96376g/mol excluding water 29.3241g/mol including 2% water # 99.99962% of atmospheric gases Airfoil A device used to induce unequal pressure on both faces for the purpose of inducing lateral movement or force. Alkaline A base substance at the high end of the pᴴ scale (7<14) Alkalines turns pink litmus paper blue but does not affect blue litmus paper The alkaline component of water is OH⁻. Mix alkaline with acid and the resultant substance tends towards neutral Alloy An alloy is a compound (mixture) of more than one metal. A steel alloy normally refers to an iron compound with more than trace amounts of elements other than and in addition to: carbon, manganese, phosphorus and sulphur. Alpha Iron Pure iron (< 1,183 K) with a body centre cubic crystal structure will contain up to 0.001% carbon in solution Alpha Particle A kinetic proton ejected from an atom's nucleus as a result of fissionable decay. Note: CalQlata refers to each released proton as an alpha-particle, as opposed to convention, which refers to two released protons as a single alpha-particle. Because neutrons are created in pairs (two electrons per shell) they are also split in pairs; two protons and two electrons. Kinetic (released) protons are alpha particles and their released electron partners are beta particles. Note: Fissionable decay also releases neutron energy in form of heat if the proton is not released from its nucleus after splitting. This can occur to either one or both of the protons released simultaneously. If both protons are retained, the atomic number [of the atom] will be altered by +2 If one proton is released (one alpha particle) and one is retained, the atomic number [of the atom] will be altered by +1 If both protons are released (two alpha particles), the atomic number [of the atom] will remain unaltered. Alternating Current (AC) Alternating current (and voltage). Electricity that rises and falls in cycles normally in the form of a 'sine-wave' and normally between Plus and Minus the design current. AC current is normally supplied by a generator and used for high-power applications (>100W) such as free-standing industrial and domestic equipment. see also DC (electrical), Apparent Power, True Power, Phase Angle and Power Factor Alternator An alternator uses magnets and coils of copper wire to convert rotary motion into AC electricity. see also DC, Generator and Motor Altitude Height above a designated surface. It is most frequently used to define the height above sea-level at the earth's surface. Ampere (A) Unit of electrical current. One Ampere is equal to one coulomb (of electrons) passing through a conductor in one second. Amplitude A displacement that represents half the total fluctuation in a complete cycle, or the maximum deflection of a beam or particle from a central datum Anaerobic Respiration that does not use free oxygen to generate energy E.g. in parasitic flat worms, yeast and occasionally in muscle tissue, all of which break down the respiratory substrates into simpler organic compounds Angle of Repose (θ) The smallest angle at which an object will slide down a flat surface under its own weight (or contact force) excluding the effects of stiction, chemistry or magnetism Angular Acceleration(α) This value may be interpreted as the second derivative of the angular rotation of a point on the circumference of a circle, which may described mathematically thus: distance: s = ω.t + ½.α.t² velocity: δs = ω + α.t . δt acceleration: δ²s = α . δt² example units for which are; ᶜ/s² (radians (θ) per second-squared). where: s = distance ω = initial velocity t = elapsed time for 's' α = acceleration see also Linear Acceleration and Rotational Acceleration Angular Velocity(ω) This value may be interpreted as the first derivative of the angular rotation of a point on the circumference of a circle, which may described mathematically thus: distance: s = ω.t + ½.α.t² velocity: δs = ω + α.t . δt example units for which are; ᶜ/s (radians (θ) per second). where: s = distance ω = initial velocity t = elapsed time for 's' Anion A negatively charged ion. An atom or molecule that has gained excess electron(s) and is therefore attracted to an anode in an electrolyte Anisotropic A description of material proproperties that vary with direction, for example: elasticity, conductivity, permittivity, magnetism, etc. in a single crystal of a crystaline metal, such as; iron, quartz, copper, nickel, salt, etc., and the strength of wood Anneal(carbon steel) To anneal a carbon steel is to soften it. This process is also referred to as stress relieving. Forged carbon steel is annealed by heating it to between 500°C and 700°C and holding it at this temperature to allow recrystallisation to occur, followed by artificial cooling. Cast carbon steel is annealed by heating it above 723°C and holding it at this temperature to allow all the material to transform to austenite, followed by artificial cooling. Artificial cooling means more slowly than it would cool in still air and is normally carried out in an oven. Anode A positively charged electrode that loses cations to a negatively charged electrolyte (corrodes) Anti-Knocking Agent The anti-knocking agent used in petrol in most developed countries today is AK-33-X (cyclopentadienyl-Manganese-Tricarbonyl) Its octane number can be increased by adding a solvent mixture called BTX (Benzene, Toluene and Xylene) The anti-knocking agent used for petrol in the past was TEL (Tetra-Ethyl-Lead:64%, Ethylene Bromide:25%, Ethylene Chloride:9% and Methylene Dye:2%) Aphelion The furthest point an orbiting body gets from its attracting mass Whilst this term can also be used instead of Apogee (i.e. it means the same thing), it is normally used to describe the point at which the distance between sun and its orbiting planet is greatest This term is made up of the Greek prefix ap for 'away from' or 'farthest point', and helion from 'Helios' the Greek sun god. a = half the width of the elipse e = its eccentricity see also Perigee and Perihelion Apogee The furthest point an orbiting body gets from its attracting mass Whilst this term can also be used instead of Aphelion (i.e. it means the same thing), it is normally used to describe the point at which the distance between the earth and its orbiting moon is greatest This term is made up of the Greek prefix ap for 'away from' or 'farthest point', and the Greek word gee for the earth. a = half the width of the elipse e = its eccentricity see also Perigee and Perihelion Apparent Power (electrical) Apparent power is the maximum theoretical power of an alternating current (peak current multiplied by peak voltage) and is normally expressed in terms of 'VA' or 'kVA'. see also AC, True Power, Phase Angle and Power Factor Arc A curved line that forms part of the circumference of a circle Area Moment A property of the cross-sectional area of any structural body that defines its ability to resist bending or torsion Armature A low-reluctance ferro-magnetic body (keeper) for temporarily bridging the poles of a permanent magnet to reduce the leakage field and preserve magnetisation in DC motors and generators. Aspect Ratio The ratio between two physical dimensions For example: length to width (L:W) or external diameter to internal diameter (OD:ID) Aspect ratio's may also be reversed according to user preference. I.e. width to length (W:L) Astroid (curve) A special case of hypocycloid curve generated by a point on the circumference of a circle rolled around the the inside of a stationary circle four times the diameter without slipping. see also Hypocycloid Atmospheric Pressure(a, atm) Atmospheric pressure refers to the pressure surrounding your subject or location. The units used for defining pressure above atmospheric are normally given the suffix 'a' or 'atm' Atmospheric pressure will vary according to the density of the surrounding gases (air). At sea-level and on dry land, atmospheric pressure is approximately equal to 14.7psi or 0.1N/mm² (1 atmosphere) When specifying absolute pressures (those that include atmospheric) you should qualify the units with 'a' or 'atm'; e.g. p = 145psia or 1.1 N/mm²[a] When quoting pressures above atmospheric (those that exclude atmospheric) you should use unqualified units (without 'a' or 'atm'); its abolute value would be 14.7psi greater. e.g. p = 145psi (1N/mm²) {Note: the absolute value; p = 159.7psia (1.1N/mm² [a]) Atom The smallest constituent part of a matter, sometimes referred to as an element. All atoms comprise collections of proton-electron pairs arranged in pairs of electon shells. An atom normally comprises any number of protons, neutrons and electrons in roughly equal numbers see The Atom Atomic Element The term for all [natural] atoms comprising the same atomic number (Z) ranging from 1 to 92, which is defined by the number of Protons in its nucleus. All larger atoms (Z>92) (including plutonium), which are artificial, disintigrate very quickly. As a general rule; the greater the atomic number (Z), the quicker they disintigrate. Atomic Mass Unit(amu) One 12ᵗʰ of the mass of a pure carbon atom (¹²C) 1amu = 1.6735325768E-24 One amu is the reciprocal of Avogadro's number Atomic Number(Z) The number of protons in the atom Atomic Particle The proton, the electron and the neutron. Austenite Face centre cubic iron, which occurs at temperatures higher than 723°C (also called Gamma Iron). At 723°C austenite can absorb up to 0.83% carbon within its crystal structure and hold another 0.87% in solution. When cooled below 723°C austenite containing 0.83% carbon will form pearlite (eutectoid steel) and the remaining iron and carbon will form ferrite or cementite dependent upon whether the steel contains less or more than 0.83% carbon. see Carbon Steel Autoclave A thick-walled pressure vessel used for heating gases under pressure Autoclaves are generally used for facilitating chemical reactions that require carefully controlled heat and pressure over a period of time, such as using steam to vulcanise rubber. Avogadro's Number(NA) The number of atoms in 12 grams of pure carbon (¹²C): it is numerically equal to 1/mₙ {/grammes} Historically, this value has been specified as; NA = 6.02214129E+23/mol but because the mass of a neutrons is 1.6735325768E-24 g; NA = 5.97538412973187E+23/mol Avogadro's number is also the reciprocal of one atomic mass unit in grammes see also mole Axial Along the longitudinal axis. Azimuthal Quantum Number (ℓ) 'ε' The second in a set of quantum numbers that describes the angular momentum (or shape) of an atomic orbital The azimuthal quantum number of an electron can only be a positive integer: i.e. 1, 2, 3, 4, 5, 6, 7, etc. The orbital shape options in any shell are normally identified with the letters; s, p, d, f, etc. Whereas the azimuthal quantum numbers for each shape are defined thus: s(ℓ=1), p(ℓ=2), d(ℓ=3), f(ℓ=4), etc. At least one other quantum number must be different for each electron in the same shell with the same azimuthal quantum number Bar Alternative term for a beam but usually used for those with a circular (or regular) cross-section. Baryon 'ε' A family of composite particles made of three quarks which includes protons and neutrons Baryons are strongly interacting fermions and part of the hadron particle family Baryon Number 'ε' One third of the number of quarks the particle contains For example: Any quark is given a Baryon number of ⅓ Any anti-quark is given a Baryon number of -⅓ Protons and neutrons are both given a Baryon number of 1 Anti-protons and anti-neutrons are both given a Baryon number of -1 Basic Oxygen Process A steel making procedure It is essentially the same as the Bessemer Converter but blows pure oxygen instead of air through the nozzles. It produces better quality steel and has largely replaced all Bessemer 'air-blowing' systems. Basic Temperture(Ṯₓ) {© 30/10/22} The lowest possible temperature in the universe, representing the EME radiated by all of its celestial bodies. Ṯₓ = 2.04274907568265 K see particle constants seel also Temperature Bead Wire A wire approximately 1mm diameter manufactured from 'Plow Steel', which is then drawn down to form the filaments used in wire ropes The term 'Bead Wire' comes from its use in untreated form to support the rim (or bead) of a tyre Beam An elongated body to which a transverse load is applied Bearing Strength The ability of a material or a body to support pressure without collapse or plastic deformation 'Bearing Stress' is the measurement designation for this property see also Stress Bending Moment A force applied at a distance that induces bending in a body Berm A heap or pile of material (soil, sand, rocks, etc.) normally positioned to protect and/or prevent movement of a structural object (e.g. pipeline) Bessemer Converter A steel making furnace It is a large steel vessel supported on pivots with one spouted opening in the top. Air is blown through a number of nozzles in the flat base to increase applied heat. Oxygen in the air is converted to carbon-dioxide see also Basic Oxygen Process Phosphorous is removed from the iron by using an alkali vessel lining, which permitted the wide use of lower quality iron ores in the production of high quality and specialist steels. This process is gradually being replaced by the Open Hearth furnace Beta Particle An electron ejected from an atom's nucleus as a result of fissionable decay. Note: CalQlata refers to each released electron as a beta-particle, as opposed to convention, which refers to two released electrons as a single beta-particle. Because neutrons are created in pairs (two electrons per shell) they are also split in pairs; two protons and two electrons. Released electrons are beta particles and their released proton partners are alpha particles. Note: In reality, fissionable decay also results in the release of neutron energy in form of heat if the proton is not released from its nucleus after splitting. This can occur to either one or both of the electrons released simultaneously. Birdcaging The term used to describe the unwinding and opening up of a wrapped assembly such as a wire rope or HPHT flexible pipe when it is axially compressed or twisted against the helical lay direction Bisector A line that passes through the centre of another line or object thereby dividing it exactly in two A perpendicular Bisector is a line that passes through the centre of another line or object at right-angles to it Black-Hole 'ε' A fictitious entity with sufficient mass to generate the gravitational energy that will prevent photons from escaping its surface minimum mass: 2.7234E+38 kg minimum radius for active star that should collapse into a black-hole: 3.5861E+11 m see Black Holes see also the Sun Body Centre Cubic (bcc) Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain nine closely packed atoms, eight of which are located at each corner of a cube and one in its centre. Bohr Radius(aₒ) Boltzmann Constant(KB) Defines the amount of energy (Joules or ft.lbf) in each particle of an ideal gas for each degree of temperature (K or R) relative to absolute zero (K=0 or R=0) KB = Rᵢ ÷ NA = 1.38065156E-23 J/K {5.657312956E-24 ft-lb/R} Also called the Stefan-Boltzmann constant as the concept was originally derived by Josef Stefan and later improved by Ludwig Boltzmann see also Gas Constant and Avogadro's Number Boson 'ε' Any particle that obeys Bose-Einstein statistics 5 are known; Higgs, photon, gluon, W & Zand1 is unknown; graviton Photon, gluon, W & Z are Gauge Bosons Bosons are normally associated with force and have integer spin properties: 1, 2, 3, 4, 5, etc. Several bosons with the same energy can occupy the same quantum state, i.e. several bosons can occupy the same place in space. Bottom Quark 'ε' Also known as the beauty quark, it has more than four times the mass of a proton and is part of the third generation of matter The bottom quark is classified as a fermion mᵣ=7.451526101E−24g [4.18GeV/c²], lifetime≈1E-12s, Q=-⅓e, Iz=-½ Brass The term used to describe a copper-zinc alloy The most common ratios (Cu%:Zn%) are: 95:5, 90:10, 85:15, 80:20, 75:25, 70:30, 65:35 & 60:40 Up to 3% lead (Pb) can be included to improve machinability but this also reduces its structural properties (slightly) As zinc content rises (see note below): The following properties increase in magnitude: yield strength, hardness, elongation, thermal coefficient of expansion The following properties decrease in magnitude: density, melting temperature, thermal conductivity, electrical conductivity 60:40 Brass is known as Munz Metal Note: this relationship holds true up to about 35% zinc after which the alloy changes phase from alpha brass to alpha-beta brass and strength drops slightly British Thermal Unit(Btu) The heat energy required to raise the temperature of one-pound (avoirdupois) of water by one degree Farenheit. Due to the erroneous belief that specific heat capacity varies with temperature, the historic values for this constant are; 1 Btu (mean) = 1055.87 Joules 1 Btu (international Table) = 1055.056 Joules 1 Btu (thermochemical) = 1054.35 Joules The genuine (actual) British thermal unit: 1 Btu = 1054.70872183582 Joules see also Calorie see specific heat capacity Brittle Any matter with unusually high viscosity The manifestation of brittleness is a body's susceptibility to shatter before achieving plastic deformation. Bronze The term normally used to describe copper-tin alloy. However, bronze is also used to describe copper-aluminium, copper beryllium and copper manganese alloys. The most common ratios of copper-tin alloys (Cu%:Sn%) are: 98.75:1.25, 95:5, 92:8 & 90:10 Up to 0.4% phosphorus can be added to bronze to improve its castability but this also hardens it As tin content rises: The following properties increase in magnitude: yield strength, hardness, elongation, thermal coefficient of expansion The following properties decrease in magnitude: density, melting temperature, thermal conductivity, electrical conductivity Brown & Sharpe Taper A conical shaft and mating sleeve for machine-part self-holding applications that optimises assembly load, holding capacity and easy release (without damage). The tapered shaft is normally driven by an End-Tang (or Key) or a Longitudinal Key. Different size numbers (0 to 16) relate to different engaged lengths (1-5/16" to 9") As each size is based upon standard fraction lengths and diameters, not all tapers will have exactly the same taper (angle ≈ 2.4°). The tapers range between 0.04167 and 0.043 inches per inch (2.39° to 2.46°) The Brown & Sharpe Taper is used for similar applications to the Morse and Jarno Tapers Bulk Modulus(k) Relationship between a 2-D stress (load per unit area) and the resultant 3-D strain in a body. the general formula for this property is; k = E ÷ 3.(1-2.ν) The bulk modulus for compressible substances such as gases is sometimes specified as follows; k = (p₂-p₁) / [(V₂-V₁)/V₁] where: p₁ = initial pressure p₂ = final pressure V₁ = initial volume V₂ = final volume Or it could be expressed thus: k = V₁.δp/δV where: δp = variation in pressure δV = resultant variation in volume V₁ = initial volume Or, because the mass does not change, it could also be expressed thus: k = V₁.δp/δρ where: δp = variation in pressure δρ = resultant variation in density ρ₁ = initial density Buoyancy The vertical (anti-gravity) force exerted by a body immersed in a fluid A body with a lower density than its surrounding fluid will float or rise (positive force) A body with the same density than its surrounding fluid will settle mid-column (zero force) A body with a greater density than its surrounding fluid will sink (negative force) Bush (m/c) A hollow cylindrical sleeve or spacer between a shaft and its housing. Contrary to plain bearings, bushes are normally used for slow-relative speed longitudinal guidance rather than high-speed relative rotation. Calorie(cal) The heat energy required to raise the temperature of one-gramme of water by one degree Celsius. Due to the erroneous belief that specific heat capacity varies with temperature, the historic values for this constant are; 1 cal (mean) = 4.1900208 Joules 1 cal (international Table) = 4.1868 Joules 1 cal (thermochemical) = 4.184 Joules The genuine (actual) calorie: 1 cal = 4.18542247371685 Joules see also British Thermal Unit see specific heat capacity Capacitance(C) Capacitance (the unit of measurement is the 'Farad') is the resistance generated by the storage of Volts as current grows in an AC power supply. This voltage is slowly released as current falls. It is the retardation of current growth caused by the storage of Volts that creates capacitive resistance. Current leads voltage C = Q/V where: V = voltage, Q = total electric charge Capstan A general term used by CalQlata to describe not only a quay-side capstan but any cylindrical surface such as a tree or drum Carbide A binary compound of carbon and a metal Typical metals that form carbides are: iron, chromium, tungsten, vanadium, molybdenum, titanium and manganese Carbon Dating The aging of matter by measuring the half-life of the carbon-14 atom. Carburise The process of transferring carbon into the surface of a carbon steel to case harden it. It is carried out by immersing or embedding the steel in a carbon rich substance and heating it to a temperature where the transfer of carbon atoms occurs. The longer this process is maintained, the greater the depth of hardening. Cardioid (curve) A special case of epicycloid curve generated by a point on the circumference of a circle rolled around the the outside of a stationary circle exactly the same size without slipping. CartesianCo-Ordinates The definition of a vector using its linear dimensional relationship to the origin of a set of 2-D (x,y) or 3-D (x,y,z) axes see also Polar Co-Ordinates and Vector Case Harden A process during which only the outer skin (or case) of a carbon steel is hardened. The inner body of the material retains its original ductility/toughness. Cathode A negatively charged electrode that gains cations via a negatively charged electrolyte (gains matter) Cation A positively charged ion. An atom or molecule with a shortage of electron(s), which is therefore attracted to a cathode in an electrolyte Cementite(Fe₃C) A very hard and brittle iron carbide that forms when excess carbon cannot be held in solution in iron Pure cementite has the following physical properties: BHN; ≈550UTS; ≈270ksiYS; ≈260ksielongation; ≈0% see Carbon Steel Central Force Motion Describes the movement of an orbiting body (its deviation from a straight-line path); e.g. a planet towards its sun or a moon towards its planet due to their gravitational attraction. The force responsible for this motion is 'centripetal' see also Force Centre Centre of Buoyancy(CofB) The centre of mass of the fluid displaced by an immersed body Centre of Gravity(CofG) The only point on a line, shape or object that can be supported on the end of a pin without the line, shape or object tilting (also known as the centre of area or centre of mass) Centrifugal The outward action of a point or body in a circular motion about a centre-point or anchor. This outward action may be energy, force or dimension. see also Centripetal Centrifugal Acceleration The positive radial (outward) acceleration of an orbiting body directed away from its centre of rotation (or force centre) (the opposite of centripetal acceleration) Centrifugal Force Centrifugal acceleration of a body multiplied by its mass (the opposite of centripetal force) see also Central Force Motion and Force see Laws of Motions Centripetal The inward reaction of a point or body in a circular motion about a centre-point or anchor. This inward action may energy, force or dimension. see also Centrifugal Centripetal Acceleration The negative radial (inward) acceleration of an orbiting body directed towards its centre of rotation (or force centre) e.g. gravitational acceleration is 'centripetal' (the opposite of centrifugal acceleration) see Laws of Motions Centripetal Force Centripetal acceleration of a body multiplied by its mass (the opposite of centrifugal force) see also Gravitational Force, Central Force Motion and Force see Laws of Motions CFC Chlorofluorocarbon - an organic gaseous compound used as a refrigerant and as a pressuriser in aerosol cans. CFCs have mistakenly been blamed as the cause of a hole in an ozone layer Charge Capacity(Qᵥ and Qᵨ) The quantity of electrical energy in a charged particle This value does not vary with temperature Qᵥ = q.qᵥ J Qᵨ = q.qᵨ J where; q = particle charge Charge Capacity of an Electron: Qᵥ = 2.05489784024488E-23 J (constant volume) Qᵨ = 3.424829733741470E-23 J (constant pressure) Charge Capacity of a Proton (with an electron parner): Qᵥ = 3.773103033591500E-20 J (constant volume) Qᵨ = 6.288505055985840E-20 J (constant pressure) The units of measurement are J, Btu, W.s, N.m, lbf.ft, etc. Charge Density see radiation Charm Quark 'ε' The third most massive of all the quarks and part of the second generation of matter The charm quark is classified as a fermion mᵣ=2.299633653E−24g [1.29GeV/c²], Q=⅔e, Iz=½ Chord A straight line that joins both ends of an Arc Circle The locus generated by rotating a point at a constant distance (R) around a central origin (O) Where; R² = x² + y² 'a' and 'b' define its centre with respect to a set of co-ordinates and 'x' & 'y' define a point on its circumference with respect to 'a' and 'b' and like an ellipse: x²/a² + y²/b² = 1 eccentricity = 0 see Elliptical Curves see also Conic Circulation(Fluidics)(K) The angular momentum of the fluid in a vortex. Whilst this property is also called cirularity or strength, it is actually Isaac Newton's constant of motion. which applies to all orbital matter; it has the same formula and the same units: K = vT.r = ζ.δA (m²/s) Where: vT = the [orbital] tangential velocity of the fluid r = the [orbital] radius of the fluid δA = change in area of rotation (sector; δA = ½.θ.r²) {per second} Clamped End A fixed support Clutch A frictional connection between a drive-shaft and a driven-shaft. The principal advantages of a clutches are, the ability to: connect and disconnect with no consideration to relative positioning and protect driven equipment by altering frictional coefficient (i.e. allowing the clutch to slip under excessive torque) Coefficient A ratio of similar properties, and therefore dimensionless. Normally used to make a calculated value more representative in the real world. Using drag coefficient as an example; Bernoulli's formula for the calculation of a fluid load on a pipe without a coefficient would look like this; F = ½.ρ.A.v² which would be unrealistic, as it presumes the entire face presented to the moving fluid is normal to the direction of flow. But this isn't the case, as can be seen in the image. Therefore, in this case, we apply what we consider to be a representative ratio of lengths (ℓ₂:ℓ₁ or ℓ₂÷ℓ₁) to the above formula to compensate for the non-flat pipe surface. In other words, in the calculation, we replace the diameter of the pipe (ℓ₁) with the height of a flat box (ℓ₂) of equvalent dimension, but normal to the fluid flow. I.e. we multiply Bernoulli's force by a ratio of lengths; F = CD.½.ρ.A.v²; giving a more representative calculation result. Coefficients are established through mathematics or experimentation. see also Factor Coefficient of Expansion(α) A factor representing the linear relationship between temperature and dimensional change in metals There are coefficients for; linear expansion (α): δl = l.α.δṮ area expansion (α'): δA = A.α'.δṮ cubic expansion (α"): δV = V.α".δṮ where δṮ = the change in temperature V = volume A = area l = length Coefficient of Friction(μ) A factor representing the linear relationship between the contact force of two surfaces and their relative sliding resistance F = μ.W (where F = force required to overcome frictional resistance and W = contact force between surfaces) μ = the tangent of the Angle of Repose Column An elongated body onto which an axial load is applied Combined Stress(σₑ) Normally interchangeable with equivalent stress When differentiating between two different types of combined stress, CalQlata uses the following specific definitions: Combined stress - the combination of similar types of stress i.e. shear or primary Equivalent stress - the combination of different types of stress i.e. shear and primary see also Stress Commutator(electrical) A means whereby induced current may be transmitted between a rotating armature and a stationary electrical circuit. Comprises a split slip-ring or bush that is electrically connected to a conductor within, and attached to, a rotating armature. Stationary brushes are pushed (via springs) onto the outer surface of the commutator to transmit electricity between the stationary conductor and the rotating conductor. The split in the ring (or bush) is to ensure that the electro-magnetic current travels in the same direction through the conductor (as the armature rotates). The current would otherwise reverse direction each time the armature passed through 180° of rotation. Compressibility Factor(gas) Defines a gas's ability to deform under compression It is calculated as follows: Z = P.V ÷ n.Rᵢ.T Z = p ÷ ρ.Rₐ.T where: p = gas pressure V = volume of gas ρ = gas density T = temperature of the gas (abolute) n = number of moles of gas (mass÷RAM) See Pipe Flow+ (Fig 1) Concave A surface that deflects inwards from a flat plane Conduction see heat Conductor A material that allows free movement of its electrons when exposed to a potential difference This term is relative. You can have a good conductor and a bad conductor. The better the conductor, the easier its electrons flow see also Resistor Conic A curve generated by a plane cutting through a circular cone The curve is defined by the locus of a point, whose distance from a fixed point (called the focus) is a constant ratio to its distance from a fixed line (called the directrix). This ratio is called the eccentricity (e) If e = 0 the curve is circular If e < 1 the curve is elliptical If e = 1 the curve is parabolic If e > 1 the curve is hyperbolic The upper cone is a nappe and the lower cone is another nappe Constant of Motion(h) Newton's angular momentum without the mass component, which applies equally to satellites (celestial - elliptical and atomic - circular), and their force-centres. Orbital: h = R.v (m²/s) where; 'R' is orbital radius and 'v' is coincident velocity electron: hₑ = Rₙ.c = 8.4479654849081E-07 m²/s proton: hₚ = Rₙ.c / √ξᵥ = 4.90577260468268E-10 m²/s Whilst a proton is not in a natural orbit, because it possesses mass, it too has a constant of motion. see Laws of Motion see also kinematic viscosity Constant of Proportionality(K) Newton's dimensional orbital constant, which applies to every orbit encircling the same force-centre, but differs for each (force-centre). This constant applies to elliptical (celestial) and circular (atomic) orbits. K = (2π)² / G.m = t²/a³ {s²/m³} where; 'm' is the force-centre mass 't' is orbital period 'a' is half the length of the orbital major-axis Convection see heat Convex A surface that deflects outwards from a flat plane Co-ordinate(s) Linear distance(s) between two points in space relative to a 3-dimensional axis system. Coriolis Effect: the directional influence on a vortex at the surface of a planet (e.g. the earth), which is defined by the relative rotational direction of the earth's surface spin and its moon’s orbit. This is why free (natural) vortices rotate in an anti-clockwise direction (positive rotation) in the earth’s northern hemisphere and clockwise (negative rotation) in the southern hemisphere. Force: the magnetic (gravitational) influence of the moon on the fluid vortex. This tends to be considerably less than the physical forces induced by fluid head, pressure, velocity, etc. but sufficient to influence [initialise] rotational direction. This force varies over the earth's surface according to latitude. The greatest forces occur at the earth's poles and the least (≈0) at the equator, where the switch between positive and negative rotation occurs. Corrosion Corrosion is the process whereby a metal is degraded and/or its atoms are removed chemically 'Rust' is a special case where oxidisation is the chemical process that occurs in iron via an electrolyte Coulomb(C) The unit of electrical charge (or work): 1 C = 1 Amp.sec One Coulomb is approximately equal to the charge of 6.24150964505573E+18 electrons where charge = 1 elementary charge unit (e) i.e.; 1 C = 6.24150964505573E+18 e The pipeline analogy for Coulomb is the volume of fluid flowing along a pipe see also Voltage Coulomb's Law The force of attraction or repulsion (F) between two charged points is proportional to the product of their charges (Q₁.Q₂) and inversely proportional to the square of their speration distance multiplied by the relative permittivity (d².ε) of the medium: F = Q₁.Q₂ ÷ d².ε N where ε is the relative permittivity = εₐ/ε₀ and εₐ = actual permittivity Coulomb's constant of proportionality (k) changes the above relationship to: F = k.Q₁.Q₂ ÷ d².ε N Note: the relative permittivity at atomic level is generally regarded as 1.0 as εₐ is unlikely to vary from that in a vacuum (ε₀), as such; at atomic level... F ≡ k.Q₁.Q₂ ÷ d² N Coulomb's Constant(k) Charles-Augustin de Coulomb's constant of proportionality for electrostatic force k = mₑ.c².Rn/e² kg.m³ / C².s² per metre where: e = elementary charge (C) Rn = neutronic radius (m) mₑ = mass of an electron (kg) c = speed of light (m/s) Coulomb's constant for a proton: k' = k/ξₘ see also Coulomb's 'k' & Coulomb's Law Coupling Ratio(φ) A universal constant that defines the ratio between gravitational force (Fg) and electrostatic force (Fₑ) φ = Fg/Fₑ = 4.40742111792333E-40 See Rydberg Atom Covalent Bond Historic explanation: The sharing of pairs of electrons between atoms, which can only occur between electrons in the valence shell (including sub-shells) of atoms I.e. there must be an electron and a gap in the valence shell of both atoms for bonding to occur. The number of valence shell 'electron+gap' permutations defines the maximum number of bonds an atom can make For Example: Helium has two electrons and no gaps in its outermost shell, therefore it cannot form a covalent bond with another helium atom (2.He ≠ He₂) Carbon has four electrons and four gaps in its outermost shell and an atomic number of 6: Its electrons are therefore distributed as follows: 1s² + 2s² + 2p² = 6 Its valence shell contains 4 electrons (2s² + 2p²) and 4 gaps(2pˉ⁴) that can be shared/paired with 4 other electrons in the valence shell of another atom. Carbon can therefore generate up to 4 bonds by pulling in four electrons from other atoms to fill its four gaps e.g.; methane (CH₄) or Ethyne (C₂H₂) or it can combine with other carbon atoms;2.C = C₂; 3.C = C₃; 4.C = C₄ Whilst covalent bonds normally occur between non-metal atoms (carbon, hydrogen, oxygen, nitrogen, etc.), they also occur between some metals and non-metals, e.g. beryllium and aluminium both form covalent bonds with chloride atoms. However, there are no valencies in atomic electron shell's, so the above explanation is hypothetical. Covalent bonding is simply the sharing of magnetic field energy between adjacent atoms. Creep The gradual and continual movement or distortion of an object or substance under load over time. Typical substances susceptible to creep are those will little elasticity such as soils and polymers Critical Pressure (cp) The pressure at which a gas will change state to a liquid at its critical temperature. E.g.; Air: 3.77MPa, Helium: 0.229MPa, Hydrogen: 1.23MPa, Nitrogen: 3.39MPa, Oxygen: 5.04MPa, Carbon Monoxide: 3.499MPa, Carbon Dioxide: 7.397MPa, Ethane: 4.884MPa, Butane: 3.798MPa, Chloroethane: 5.269MPa However, given recent discoveries concerning the atom and the states of matter (Fig 2), 'critical states' can only be theoretical. Critical Temperature (ct) Gas: The temperature above which a gas cannot be liquefied by pressure alone. E.g; Air: 133K, Helium: 5.26K, Hydrogen: 33.26K, Nitrogen: 126K, Oxygen: 154.37K, Carbon Monoxide: 133K, Carbon Dioxide: 304.26K, Ethane: 305.37K, Butane: 426.15K, Chloroethane: 460.37K Magnets: The temperature (Curie temperature) above which magnets lose their magnetic properties. E.g; Iron: 1043K, Cobalt: 1400K, Nickel: 631K Solids: The temperature above which a solid changes state or undergoes a fundamental change of its properties However, given recent discoveries concerning the atom and the states of matter (Fig 2), 'critical states' can only be theoretical. Crooke's Tube A sealed, evacuated glass tube in which an electrode is installed at each end. A voltage is passed across the two electrodes that materialises in the form of a path of light. The source of the light is the electro-magnetic energy emitted as a result of the interaction between transmitted electrons and the lone protons in the tube. see The Error Cross-Section A two-dimensional plane through a three-dimansional body. Crucible Furnace A Crucible furnace is used to manufacture consistently high-quality steel. It is a very high-temperature melting process that isolates the steel from the fire in order to ensure total control over the carbon content. The crucible is a small to medium cylindrical vessel made from fireclay that is sealed with a lid and placed into a fire. Modern steelmaking methods can achieve almost the same level of quality but much less expensively. Crystal (metals) A crystal of any metal is a single body (of any size) containing purely its own atoms (i.e. no impurities) all of which are arranged in prisms (trihedron, quadrahedron, pentahedron, hexahedron, heptahedron, etc.) with the same orientation and spacing in a consistent lattice structure, for example: As a crystal grows, each face of every prism (or cube) in the lattice structure will also form the face of a neighbouring prism (or cube). Cubic Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain eight closely packed atoms, each of which are located at each corner of a cube. Cubic Expansivity(α") Curie Point The point at which a material changes to or from being ferromagnetic to paramagnetic or diamagnetic Some examples are provided below: Iron: 1,040K Steel: 1,039K @ C:0.01% to 996K @ C:0.83% Neodymium: 593K Cobalt: 1400K Gadolinium: 292K Terbium: 237K Dysprosium: 88K These changes occur at temperatures at which an element alters its lattice structure. Current(electrical)(I) The the flow-rate of electrons along an electrical conductor due to a potential difference. The unit of measurement is the Ampere. One Ampere is equal to one coulomb flowing in one second. The pipeline analogy for current is the rate of volumetric flow of the fluid along a pipe I = V.R where; R = resistance and V = voltage Curvilinear Velocity Cycle(thermodynamics) A 'Process' that returns a heat engine to its original state Cycloid (curve) A cycloid is a curve generated by a point on the circumference of a circle that is rolled along a flat, straight surface without slipping. see also Trochoid, Epicycloid and Hypocycloid Dalton's Law The pressure of any gas in a mixture of gases is equal to the pressure it would exert if it occupied the same volume alone at the same temperature. i.e. each gas within in a mixture of gases will behave as though the other gases are not present. Each gas will expand independently until its pressure is the same everywhere throughout the container but not necessarily the same pressure as any other gas in the container. The pressure of each gas in a mixture of gases is called a 'partial pressure'. Total pressure of a gas mixture is equal to the sum of the individual gas pressures. All same-element atoms (and molecules) will repel according to their lattice-structures. Damage Ratio(Ƞ) Also known as 'utilisation' (the reciprocal of safety factor) is a number that describes the likelihood that a mechanical component or material will survive its design life. A value of 'one' predicts that the component will fail on the last cycle of its design life with no safety factor. A number less than one reveals a component that will last longer than its design life whilst a number greater than one shows a component that will fail before the end of its design life Damping (vibration) The reduction or avoidance of harmonic excitation (resonance). May be achieved by keeping the operational frequency (ƒ):ƒ < 0.5 x ƒⁿorƒ > 1.4 x ƒⁿ Damping Factor(ζ) The ratio of damping (C) to critical damping (Cc): ζ = C ÷ Cc also know as a damping ratio ζ < 1.0 is considered under-damped ζ = 1.0 is considered fully damped ζ > 1.0 is considered over-damped de Broglie Wavelength(λ) The wavelength of a particle due to its momentum λ = h/p where: h = Planck's constant p = momentum Deflagration Sudden burst into flames see also Explosion Deformation Energy(Uᴰ) Energy absorbed/dissipated in the combined deformation of an impacting mass and the impacted system or body Elastic deformation energy: Uᴰ = ½ky² = ½Fy {F is the average force: F̌ = 2F and F̂ = 0} Plastic deformation energy: Uᴰ = Fy {m.a.y} {F remains constant until momentum ceases} Where: k = spring coefficient (see Hooke's law) y = combined deformation of body and mass m = mass of body a = decceleration rate of body on impact Degrees of Freedom There are six degrees of freedom; three vectors (or directions) according to the right-hand rule (x,y,z) and three rotations (xy,xz,yz) On a ship these six degrees of freedom are known as Surge, Sway, Heave and Yaw, Pitch, Roll respectively Delta Iron Pure iron (> 1,663 K) with a body centre cubic crystal structure Density (ρ) The mass per unit volume of a body or substance, measured in kg/m³, lb/in³ or g/cm³. e.g. 1.0 m³ of a substance with a density of 3000 kg/m³ will have a mass of 3000 kg. The ultimate (limiting) density is that of an atomic particle:ρᵤ = 7.12660796350449E+16 kg/m³ see also Specific Gravity, Specific Volume and Newton's Mass Design Life The predicted period of time until immediately before a material or mechanical component is no longer expected to comply with its original design specification Deuterium (atom)(D) A proton-electron pair with one neutron attached. see also Hydrogen and Tritium Dew-Point(vapours) The combined temperature and pressure at which the liquid in a vapour begins to condense An increase in pressure and/or a reduction in temperature of the vapour will cause this to occur Dezincification The removal of zinc from an alloy due to corrosion or heat The result of which is to reduce its effective percentage quantity in the alloy along with its beneficial effects Diaphragm A sheet of thin material designed to hold fluid pressure on one side only and deflect without damage. Frequently designed to allow the passage of gases. see also Membrane Diamagnetism The repulsion of a non-magnetic material from a magnet (magnetic repulsion tends to be weak) Diatomic (gas) A gas (mixture or pure) comprising only molecules of two atoms, such as nitrogen, oxygen, fluorine, chlorine, etc. Dirac's Constant(ħ) ħ = h ÷ 2π = 1.05457207144921E-34 J.s where: h = Planck's constant Direct Current(DC) Direct current Steady-state current (and voltage) that does not vary in cycles (see AC). DC current is normally supplied by battery and used for low-power applications (<100W) such as mobile phones, computers and hand-held tools. DC generators are also used for DC power supply but much less frequently (than for AC power). Disorder(thermodynamics) A measure of randomness in the molecules that compirise a system (e.g. gas, liquid, solid, etc.) Randomness, and hence disorder, increases as molecules move further apart and/or move out of alignment, such as in crystaline arrangements, which occurs due to an increase in temperature and/or through decay. see also System, Crystal (metals) and Entropy Distributed Load Also known as a line load, is applied (not necessarily equally) to a body along a line (not necessarily straight) and denoted as a load per unit length Down Quark 'ε' One of the two types of quark that make the proton and the neutron and forms part of the first generation of matter The down quark is classified as a fermion mᵣ=8.538949767E-27g [4.79MeV/c²], Q=-⅓e, Iz=-½ Drag Coefficient(Cd) A coefficient that represents the resistance between a fluid and a surface over which it is passing and with which it is in contact Such resistance is due to two conditions: 1) The magnetic attraction between the atoms in the body and that in the environment. 2) The surface area of the body. 3) The surface roughness of the body. Relatively smooth surfaces and low profiles will have a low drag coefficient (< 0.7) whilst rougher surfaces and high profiles will exhibit higher drag coefficients (> 0.7) Whilst there are certain circumstances where a drag coefficient can exceed 1.0, it is a rare occurrence Draw The process of reducing the diameter of a filament (single or individual metal wire) by pulling it through a small die Duplex (stainless steel) A stainless steel containing approximately equal proportions of Ferrite and Martensite Dynamic Amplification Factor(DAF) A factor by which a force (or weight) is multiplied in order to account for the dynamic nature of its condition e.g. F = mass x g x DAF Dynamic Pressure(q) The pressure difference induced either side of a body travelling through a gas; q = ½.ρ.v² where: 'ρ' is the density of the gas 'v' is the relative velocity of the body and the gas In reality; q ≡ p because the units are not the same q ≠ p [kg/m³ . (m/s)² ≠ kg.m / s².m²] q = p.(ℓ₁/ℓ₂) [kg/m³ . (m/s)² = kg.m/s²/m² . m/m] where ℓ₁ & ℓ₂ represent relative distances traveled at pressure 'p' see Aerodynamics E = m.c²(Henri Poincaré) {© 01/10/18} Describes the potential energy (PE) in a proton-electron pair at the instant its particles unite to become a neutron. This occurs when the orbiting electron reaches the speed of light (c): PE = -2 x KE in circular orbits KE = ½.m.c² PE = -2 x ½.m.c² = -m.c² see E=mc² & Neutron and Laws of Motion see also Neutronic Radius Earth (properties) Diameter @ poles: 12713.504km Diameter @ equator: 12756.274km Surface area: 5.09493884932169E+08km² Volume: 1.0832072662532E+12km³ Mass: 5.9645197677618E+24kg Density (average): 5506.35132682682kg/m³ Distance from the Sun: minimum: 1.471E+08 km mean: 1.496E+08 km maximum: 1.521E+08 km Tilt: 23.4° Wobble: 6.28° Eccentricity(e) The ratio of the length of an ellipse's major axis (a) to its minor axis (b) e = b/a (0 ≤ e < 1) The eccentricity of a circle = 0 The eccentricity of a parabola = 1 see Elliptical Curves see also Conic Elastic Moduli Describes the two and three-dimensional behaviour of materials under elastic deformation and includes: shear, bulk and Young's modulus along with Poisson's ratio Elastic Strain A material that returns to its pre-deformation dimensions when stress is released(i.e. obeys Hooke's Law) Elastic Stress A load per unit area that is less than the material's yield stress see also Elastic Strain Electrical Charge See Coulomb Electrical Energy(Eₑ) The energy generated by electrical charge. It may be variously described, such as; Eₑ = C.V {1 Joule = 1 Coulomb x 1 Volt} or Eₑ = Rᵢ.Ṯₙ / RC.RAMₚ {29.2372961438378 J/C} its units as Joules per Coulomb RAMₚ = relative atomic mass of a proton; 1 gramme per mole (0.001 kg/mol) Electric Furnace The Electric Furnace is a process for melting steel. It uses high current electricity to melt the steel. It can be combined with the Bessemer Converter and Open Hearth methods by dipping charged electrodes into the melt. This process is capable of very high volume production and good quality control. It is also relatively inexpensive Electricity The movement or transfer of electrical charge, which exists in both atomic particles and electro-magnetic energy. Electrode An electrical conductor (solid metal) that can transfer ions to or from an electrolyte Electrolyte A positive or negative electrically charged liquid that conducts electricity through ionisation. Seawater is a predominantly negatively charged electrolyte that will Corrode relatively positively charged metals (e.g. aluminium and zinc) and plate (coat) relatively negatively charged metals (e.g. carbon steel and tin) if immersed together. However, because water molecules are polar (they have both positive and negative probes), immersed steel will corrode in the absence of a donor material (e.g. aluminium or zinc) Electro-Magnetic Energy(EME) Polar electrical and magnetic charge energy radiated by proton-electron pairs. EME is trapped by electrons, which they convert into velocity; the magnitude of which may be calculated thus: E = h'/A where 'A' is the EME amplitude Electro-magnetic energy has no mass and travels in waves in a straight-line. Its wavelength, amplitude and frequency are all related to its energy thus: λ = c/ƒ A = R = Rₙ.(c/v)² where R is the electron's orbital radius and v is the electron's orbital velocity EME's frequency is proportional to its energy (magnitude), and its wavelength and amplitude are inversely proportional to its energy (magnitude). Electro-magnetic energy always radiates (travels) at the speed of light see Spectrum Electro-Motive Force(emf) The work done to move electrons by an electrical force (emf) across a material with electrical resistance. Whilst 'emf' and potential difference ('pd') are normally differentiated, they are essentially the same, as are their units of measurement (Volt). The electrical equivalent of 'mmf'. Electron {© 01/10/18} A single indivisible packet of electro-magnetic charge that possesses intrinsic kinetic energy. All electrons are identical. Electrons always orbit their proton partner until the two particles unite as a neutron. Its magnetic charge is non-polar and constant. Its electrical charge (e) is negative and constant. mass = 9.1093897E-31 kg, radius = 1.45046059426276E-16 m see The Proton-Electron Pair see also Neutron Electron Affinity The energy required to remove an electron from a negative ion Electronegativity A tendency for collecting electrons These numbers (between 1 and 4), as defined by Pauling, are used to determine the contribution an element will make to an ionic or covalent bond The higher the Electronegativity, the more electrons it will collect Electron Shell(s) {© 01/10/18} All electron shells except the outermost contain two electrons. The outer shell may contain one or two electrons, dependent upon the atomic number of the atom concerned. All shells are full at all times. There are no shell valencies. The spacing between each shell is equal and varies with the temperature of the atom. The fastest orbiting electrons (highest kinetic energy) are in an atom's innermost shell (shell-1), gradually reducing with shell number. The slowest orbiting electron(s) (lowest kinetic energy) is in the outermost shell (shell-n). Electron Shell(s)(and sub-shells) 'ε' Shells are numbered 1 to 7 (in the periodic table) Sub-Shells are allocated letters: s, p, d, & f The numbers of electrons in each shell are as follows: s = 2; p = 6; d = 10; f = 14 (irrespective of the shell) Shell 1: s₂ = 2 Shell 2: s₂ p₆ = 8 Shell 3: s₂ p₆ d₁₀ = 18 Shell 4: s₂ p₆ d₁₀ f₁₄ = 32 Shell 5: s₂ p₆ d₁₀ f₁₄ = 32 (Uranium) Shell 6: s₂ p₆ d₁₀ f₁₄ = 32 Shell 7: s₂ p₆ d₁₀ f₁₄ = 32 In theory; after filling sub-shell f, shell number 5 should create another sub-shell but 'f' represents the limiting force-field All atoms above 5f (Uranium) are unstable; a very short half-life (the greater the atomic number the shorter the half-life). All of which, is of course, fiction. Electron Volt(eV) The energy received by the charge of an electron due to the potential difference of 1 Volt 1eV = 1.60217648753E-19 Coulomb see also Elementary Charge Unit Element(structures) A bar, beam, plate or member that constitutes part of a larger structure but which can be analysed individually Element(atomic) Elemental Matter A body of matter comprising atoms all of which have the same atomic number. Elementary Charge Unit(e) The negative charge (-Q) carried by a single electron or the positive charge (+Q) carried by a single [lone] proton; i.e. a proton that is not part of proton-electron pair.) 1 elementary charge unit [Coulombs] =        Faraday's constant ÷ Avogadro's constant        (1e = 1.60217648753E-19C) see UniQon see also Electron Volt Elementary Particle 'ε' The fundamental particles of matter. All elementary particles are either fermions or bosons Fermions Quarks: up, down, top, bottom, strange, charm Leptons: electron, electron neutrino, muon, muon neutrino, tauon, tauon neutrino Bosons Higgs, graviton Gauge Bosons: photon, gluon, W, Z Ellipse The circumference of a flat section cut at any angle through a right-circular cylinder where; x²/a² + y²/b² = 1 eccentricity = √(1 - (b/a)² ) < 1 see Elliptical Curves see also Conic Emission (EME) Electro-magnetic energy emission by a single proton-electron pair. End Cap (force) A longitudinal tensile or compressive force in a pipe wall as a result of a variation in temperature and/or pressure see also Upheaval Buckling Energy(U & E) Essentially the same as work with the same units Energy sources can be mechanical, electrical, chemical or thermal There are three principle forms of mechanical energy: Potential (Uᴾ) Kinetic (Uᴷ) Deformation (Uᴰ) There are four principle forms of thermodynamic energy: Entropy (S) Internal (U) Heat (Q) Work (W) see Thermodynamics There are a number of atomic-nuclear energies, four of which are: Fusion Fission Gravitational Relativistic momentum Enthalpy(H)(thermodynamics) The total energy of a system H = U + Ṯ.Cp H = U + p.V + Uᴷ + Uᴾ + ... where; U = internal energy R = gas constant Cp = Heat Ṯ = temperature (absolute) Uᴷ + Uᴾ + ... = pressure, Kinetic, Potential, magnetic, chemical, gravitational, etc. energies The units of measurement are J, Btu, W.s, N.m, lbf.ft, etc. see Thermodynamics see also Energy and Specific Enthalpy Entropy(S) The measure of disorder in a system defined by energy that cannot be converted into work Entropy is only a measure of disorder; it is not a measure of temperature temperature simply affects entropy To explain ... Entropy is the basic level of energy inherent in all molecules that is defined by the following formula: KB x Ln(N) {per molecule} where KB = Boltzmann constant & N = molecule microstate which is true for all molecules even at absolute zero Note: 'N' varies with temperature, therefore entropy varies with temperature Temperature increases as heat energy is added to the above basic level. The temperature of any substance is defined by its gas constant (Rₐ) and limited by its heat capacity (cv). Therefore, as a substance gains or loses temperature (heat energy) its entropy will be affected due to its molecules moving further apart, thereby increasing disorder. So: the second law of thermodynamics remains true in that entropy (disorder) always increases with time through natural and inevitable decay (irrespective of temperature) and the third law of thermodynamics also remains true in that; as temperature decreases molecules pack closer together reducing their disorder, thereby reducing entropy Process formulas for a change in entropy such as: δs = cp.Ln(Ṯ₂/Ṯ₁) & δs = cv.Ln(Ṯ₂/Ṯ₁) are temperature dependent, and: δs = Rₐ.Ln(V₂/V₁) is a direct calculation of disorder (variation in volume) making them consistent with the above because δs is a measure of change in disorder, and all these formulas define this change due either to a variation in temperature or volume. see Heat and Thermodynamics see also Boltzmann Constant, Gas Constant, Specific Entropy and Disorder Epicycloid (curve) An epicycloid is a curve generated by a point on the circumference of a circle that is rolled around the outside of another circle without slipping. A curve generated by a point on the same circle but not on the circumference is called a 'Epitrochoid'. Special Case: The path generated by a point on the circumference of a rolling circle with the same radius as the stationary circle will be a 'Cardioid'. see also Cycloid, Trochoid and Hypocycloid Epitrochoid (curve) see Epicycloid Equilateral (triangle) A triangle with all three sides of equal length Equilibrium A state of constancy, stability and balance Equilibrium applies to mechanical, chemical, electrical and thermal systems that may be transferring energy but the exchange is constant, i.e. unchanging Equilibrium Diagram see also Phase Diagram Equivalent Stress(σₑ) Normally interchangeable with combined stress When differentiating between two different types of combined stress, CalQlata uses the following specific definitions: Combined stress - the combination of similar types of stress i.e. shear or primary Equivalent stress - the combination of different types of stress i.e. shear and primary see also Stress Errosion The removal of matter by particles in a transient fluid. Escape Altitude The altitude at which gravitational acceleration of a body (e.g. planet, star, etc.) is equal to the centrifugal acceleration due to the orbital velocity (v²/r) of a satellite holding a constant position over the body Where 'v' is the linear velocity of the orbiting body and 'r' is the distance between the centres of mass This altitude for the earth is 35843425.4809m above sea level. see also Geosynchronous Orbit Euclidian Geometry A universal method of geometric calculation (developed by the Greek mathematician Euclid 323 BC - 285 BC) based upon a few basic rules. I.e. once a few basic rules have been established, they can be used to determine a multitude of other related (and even unrelated) mathematical problems. Eutectic A mixture of two metals that are completely soluble in a molten state but completely insoluble in a solid state. As the liquid cools to form a solid, alternate layers of each pure metal will form in the crystal(s) creating a laminated structure (like plywood). Eutectoid A mixture of two metals in a solid state that are completely soluble at a high temperature but completely insoluble at a lower temperature. As the material cools to form a different lattice structure (e.g. the transition of iron with 0.83% carbon from austenite above 723°C to pearlite below 723°C), alternate layers of each pure metal (or ferrite in steel) will form in the crystal(s) creating a laminated structure (like plywood). Exosphere Stratum of the earth's atmosphere that constitutes its outer limit (Ionosphere to 1000km) Contains neutrons and protons that have been detached by the sun's electromagnetic radiation Temperature increases exponentially with increasing altitude Explosion Sudden release of energy, that is usually chemical but it can also be pressure (i.e. energy = pressure x volume) An explosion is always accompanied by an increase in heat and sometimes by deflagration. Face Centre Cubic(fcc) Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain fourteen closely packed atoms, eight of which are located at each corner of a cube and one in the middle of each face of the cube. Factor A multiplier, normally used to modify a calculated value to give a more representative or expected value, either for reasons of safety or to account for the 'unkown' (unreliable or missing data in the calculation). see also Coefficient Farad(F) The unit of electrostatic capacitance that when charged by the potential diference of 1 volt carries a charge of 1 Coulomb. Farad = Coulombs / Volt (F = C²/J) Faraday's Constant(F) The magnitude of electric charge per mole of electrons 1 F = 96485.3317942158 C/mol {exact} (F = NA . e) Fatigue The deterioration of a material due to repeated stress cycling Fatigue Life The total number of stress cycles (sum of all stress blocks) that represent the expected life of a material or mechanical component and above which damage or failure will occur Faxen/Oseen Correction Factor(β) Correction factor for calculating the forces on a sphere falling through a fluid close to solid wall (e.g. in a tank or pipe). d/r > 0.01: β = [1 - 9/16.(r/h) + 1/8.(r/h)³ - 45/256.(r/h)⁴ - 1/16.(r/h)⁵ ]⁻¹ d/r < 0.01: β = -8/15 . ln(d/r) + 0.9588 Where: h = distance from wall to centre of sphere r = radius of sphere d = h-r Fermion 'ε' Any particle that obeys Fermi-Dirac statistics Fermions include sub-atomic particles; leptons and quarks and compound particles; neutrons and protons Fermions have half integer spin properties: ½, 1½, 2½, 3½, 4½, 5½, etc. see also Pauli's Exclusion Principle Ferrite Body centre cubic iron, which can absorb up to 0.006% carbon within its crystal structure at room temperature and up to a maximum of 0.03% carbon at 723°C (also called alpha iron) Pure ferrite has the following physical properties: BHN; ≈90UTS; ≈46ksiYS; ≈36ksielongation; ≈30% see Carbon Steel Ferromagnetism Matter's ability to generate magnetism. Whilst the term 'ferro-' refers to iron, all magnetic materials may be called 'ferro-magnets'. Filament A single very thin wire or cord of any cross-sectional shape that normally forms part of a multi-filament construction, e.g. a strand see also Wire Rope Fire-Point A temperature above which a substance will give off sufficient vapour to maintain combustion This temperature is usually higher than the Flash-Point for the same substance see also Flash-Point Fission The splitting of an atom's neutrons into their component parts; a proton (alpha-particle) and an electron (beta-particle), releasing their stored energy Because neutrons are created in pairs, they usually revert to their component parts (a proton and an electron) in pairs. This revertion process can take one of two forms: The proton of the proton-electron partnership released from the neutron, cannot escape its nucleus: neutron energy is released in the form of heat. The proton of the proton-electron partnership released from the neutron, escapes its nucleus: an alpha particle and a beta particle are released. Fixed Support A support that prevents all six degrees of freedom Flammable Having the ability to catch fire under certain conditions see also Inflammable Flash-Point A temperature above which a vapour from a substance will combust if exposed to a spark or small flame It is usual to define this value on the basis of test using a Cleveland cup or Penskey-Martens apparatus This temperature is usually lower than the Fire-Point for the same substance Flexible The ability to deform significantly without breaking (the opposite of brittle). Flexural Modulus The deformation stress behaviour associated with polymers The plastic equivalent of Young's modulus Fluid A liquid or a gas The term fluid is misleading as it encompasses two disparate states; viscous and gaseous. Focal Length(of a lens) The distance along the axis of a lens between a principal plane (at its axis) and its nearest focal point. This distance (ƒ) is identical both sides of the same lens. see also Power (of a lens) Focal Point(of a lens) The theoretical point (F) of intersection between the axis of a Lens and an exiting light-ray that entered the lens parallel to its axis at a radial distance of almost zero. The primary focal point occurs at the front of a lens The secondary focal point occurs at the back of a lens Force(F) A load applied by an accelerating body (mass) on another body (mass), that may be stationary or in motion, thus changing their states of motion There are a number of specially applied forces, such as: Weight Impressed Force: a force exerted on a body in order to alter its state Centripetal Force: an attracting force between masses causing them to move towards each other; Fᵖ = m.a Centrifugal Force: a force causing a body to recede from its orbit according to the following relationship; Fᶠ = ½.m.v² / r Gravitational Force: also called weight and centripetal force; Fᶢ = m.g Force = mass multiplied by acceleration (F = m.a) Force-Centre A mass (or body) maintaining a satellite in its orbit, e.g. the force-centre of a galaxy is a galactic force-centre (stars are its satellites), the force-centre of a solar-system is a star (planets are its satellites), the force-centre of a lunar-system is a planet (moons are its satellites), the force-centre of a proton-electron pair is a proton (a single electron is its only satellite) The force exerted by a force-centre is 'centripetal' see also Central Force Motion Free Cutting Steel Free cutting steel is plain carbon steel with good machinability Plain carbon steel with more than 0.2% carbon is relatively difficult to machine because of its hardness and its embedded manganese increases this hardness. Sulphur is added to plain carbon steel to improve machinability, which it does by combining with the manganese to create manganese sulphide. This compound ensures clean chip separation without brittle fracture during machining. Free Support A support that allows all six degrees of freedom Frequency (ƒ) The number of times a cyclic event is completed in a given time period. A frequency of a number of cycles each 'second' is measured in 'Hz'. For example; a frequency of 6 cycles a second is equal to 6 Hz. Its reciprocal (1/ƒ) is the time taken to complete one cycle (¹⁄₆th of second) i.e. the cyclic 'period' The higher the frequency (i.e. the shorter the wavelength) the greater the energy in the wave The natural frequency (ƒⁿ) of an object is the frequency at which it can regenerate a complete cycle itself (free oscillation) with minimal external assistance and is dependent upon the elasticity and inertia in the system. Natural period is the reciprocal of natural frequency (1/ƒⁿ) The natural frequency (ƒⁿ) of an object is the frequency at which it can regenerate a complete cycle itself (free oscillation) with minimal external assistance and is dependent upon the elasticity and inertia in the system. Natural period is the reciprocal of natural frequency (1/ƒⁿ) The relationship between frequency and wavelength for electro-magnetic energy (e.g. light): c = λ.ƒ) Freeze The conversion of a liquid to a solid Friction Friction is the resistance to relative movement between two surfaces see also Stiction and Coefficient of Friction Frustum A pyramid truncated by a flat plane normal to its axis Fulcrum The point about which a lever or moment couple rotates Also called a pivot point Fusion The joining of elements (e.g. two hydrogen atoms to make one helium atom) by pushing the nucleus of one atom inside the electron shells of another. Fusion does not generate energy; it requires the input of gravitational energy and the absence of heat. Fusion only occurs naturally inside cold bodies of sufficient mass to generate the necessary internal pressures; i.e. galactic force-centres and the ultimate body. Fusion does not occur inside planets and stars, because they are; a) too hot, and; b) insufficiently massive Galactic Force-Centre A force-centre at the focal point of a galactic system. see The Universe Galileo'sLaws of Motion Inertia: Every object persists in its state of rest, or uniform motion (in a straight line); unless, it is compelled to change that state, by forces impressed on it (Newton's first law) Falling Objects: The distance traveled by a falling body is directly proportional to the square of the time it takes to fall Uniform motion: d ∝ t Uniform Acceleration: v ∝ t Parabolic Curve: A projectile that with a uniform horizontal and a naturally accelerated vertical motion describes a path which is a semi-parabola (i.e. half of a full parabolic curve) Terminal Velocity: A body falling from a very considerable height will reach a velocity that will remain constant due to frictional resistance from the surrounding air (see CalQlata's Fluid Forces calculator) Frame of Reference: Any two observers moving at constant speed and direction with respect to one another will obtain the same results for all mechanical experiments Galvanic Corrosion Describes the form of corrosion whereby a sacrificial metal (anode) will lose material (protons) to another metal (cathode) Whilst this phenomenon normally occurs due to both metals being immersed (or wetted) by a common liquid (an electrolyte) facilitating the electrical transfer of positively charged ions from one to the another, it can occur if both metals are joined by any similarly capable medium. The electrical property responsible for this phenomenon in metals is Electronegativity, which indicates their relative nobility Gamma Iron Pure iron (> 1,183 K) with a face centre cubic crystal structure holds up to 2% carbon in solution Gamma Radiation Very short-wave electro-magnetic energy released as a result of neutron decay, the proton of which remains trapped within the atom's nucleus. No particles are emitted as a result of Gamma radiation. However, during heavy neutron decay, the compositional proton-electron pairs of neighbouring splitting neutrons that are not retained within the atomic nucleus, will be ejected as alpha and beta particles. λ < 1.77056263481047E-14m to 1.0E-11m ʄ > 1.69320448260839E+22Hz to 2.99792459E+19Hz Gas A substance in a state whereby the electrical repulsive forces between all its atomic and molecular protons is greater than their magnetic [attractive] forces. This is a high-temperature state, in which all atoms and molecules repel all other atoms and molecules (partial pressure theory). The natural state for any gas is to equalise its 'same-element' pressures filling its container, which includes the effect of gravity. All same-element atoms (and molecules) will repel according to their lattice-structures. see also Liquid, Solid and Dalton's Law Gas Constant(R) The energy required to raise the temperature of an ideal gas by one degree It has recently been discovered ('state of matter') that this gas constant applies to both gaseous and viscous matter. Universal (ideal) constant for all gases {per mole}: Historically; Rᵢ = NA.KB = 8.314478766579 J/K/mol {3.406913797 ft-lb/R/mol} Revised NA; Rᵢ = 8.24992342031355 J/K/mol {3.38046180812176 ft-lb/R/mol} Specific (mass) gas constant {per unit mass}: Rₐ = Rᵢ/RAM = cp - cv J/K/g {ft-lb/R/lb} Gas constant {for total mass of gas}: R = Rᵢ x moles = Rₐ x mass J/K {ft-lb/R} Gas constants for sub-atomic particles (historic values): Electron: R = 1.38065156E-23 J/K (Boltzmann Constant) Proton: R = 2.53508495037794E-20 J/K Neutron: R = 2.53508495037794E-20 J/K see Heat, Thermodynamics and Steam (properties) see also Boltzmann's constant and Specific Heat(s) Gas:Oil Ratio The volumetric (e.g. ft³ or m³) ratio of oil to gas at 1 atmosphere and 60°F Gas Planet A planet that has collected sufficient satellite mass to the raise its internal [frictional] temperature to melt its surface matter. The planet we see is its atmospheric gases. Gauge Boson 'ε' Bosonic particles that act as carriers of the fundamental forces of nature General Relativity 'ε' A theory that defines the motion of objects based upon the deformation of space and gravity, based upon the misunderstanding that electro-magnetic energy (light) possesses mass. see Relativity is Dead see also Special Relativity Generator A generator uses magnets and coils of copper wire to convert rotary motion into DC electricity. see also AC, Alternator and Motor Geosynchronous Orbit The altitude where the gravitational acceleration of a planet/star equals the centrifugal acceleration on an orbitting satellite that remains continuously over exactly the same spot on the planet. R = ³√(G.m/ω²) where:R = geosynchronous orbital radius from centre of planet; G = gravitational constant; m = mass of force centre ω = rotary velocity of planet (ᶜ/s) Increased speed at this altitude will result in the centrifugal acceleration being greater than gravitational acceleration causing the satellite to drift out into space. Reduced speed at this altitude will result in the centrifugal acceleration being less than gravitational acceleration causing the satellite to fall back towards the surface of the planet. see also Escape Altitude Gluon 'ε' A strong force-carrying gauge boson or messenger particle Gluons are elementary expressions of quark interaction and indirectly involved with the binding of protons and neutrons together in atomic nuclei There are 8 types (or colour) of gluon, any combination of two from the following colours: red, anti-red, green, anti-green, blue and anti-blue whilst the above range theoretically allows 9 colour combinations, there are in fact only 8! This is because gluons naturally exist in pairs and if all pairs are full their would be no means whereby colour can be transferred (i.e. the voids {the lone or single gluons} allow the transfer of gluons between gluon pairs) A gluon is a Gauge Boson m=0g, Ø≈10ˉ¹⁵m, lifetime>10²⁹yrs, Q=0, Iz=1 Golden Ratio(Φ) A universal ratio found in nature and mathematics which was first used by Phidias (500 BC - 432 BC; after whom the value is named) e.g. it was demonstrated by Euclid to be the ratio with which the diagonals of the regular pentagon cut each other Φ-1 = 1/Φ using quadratics becomes: 1 + ½(√5-1) and equals: 1.61803398874989 Grain (crystal) A complete single crystal of similar atoms in the form of a naturally occurring lattice structure A grain of any material can also contain atoms of a different type but these atoms must be small enough to fit into the gaps (spaces) within the crystalline lattice structure of the granulated material Grain growth produces in large (coarse) grain structures resulting brittle metals Small (refined) grain structures produce more ductile metals Gravitational Acceleration(g) Where it is necessary for CalQlata to impose a default value for 'g' in any of its calculators (e.g. UniQon), the value used at sealevel is; 9.80663139027614 m/s² (which happens to be at latitude 45.5° {Milan or Minneapolis}). The reason for selecting this figure is as follows: a) ISO states that; 1lb (force) = 4.448222N (exact) b) ISO also states that; 1lb (mass) = 0.45359327kg (exact) c) The above defaulted value for 'g' appears if you divide 1lb (force) by 1lb (mass) {4.448222 ÷ 0.45359327} d) CalQlata default's to the above value for consistency between its calculators and this website The imperial equivalent for the above 'exact' value for 'g' is 32.173987500906ft/s² CalQlata's UniQon-technical help includes a facility for calculating an accurate value for 'g' (at your latitude) should you require one. Gravitational Constant(G) A universal constant that defines the gravitational attraction (force) between two or more bodies G = aₒ.c² / mN = 6.67359232004332E-11 m³/kg/s² © where: mN = ρᵤ x V (and V = unit volume = 1.0) G = φ.k.e² / mₑ.mp based upon Planck's Atom The Imperial equivalent of which is; G = 1.19176793676718E-09 in³/lb/s² see Newton's 'G' see also Gravitational Constant Gravitational Constant(gc) A dimensionless conversion constant for gravitational acceleration used in calculations dependent upon their units SI units: gc = 1.0 Imperial units: gc = 32.173987500906 Gravitational Energy) {© 01/10/18} The attractive potential energy exerted by a mass due to the combined non-polar magnetism in all its atomic particles: PE = m.g.R (negative in calculations) at radial distance 'R' see also Gravity Gravity is Magnetism Gravitational Force(Fg) {© 01/10/18} A centripetal force acting between two or more bodies that is a function of the combined non-polar magnetism in all their atomic particles: Fg = G.m₁.m₂ / R² where 'm₁' and 'm₂' are two attracting masses separated by radial distance 'R' Graviton 'ε' Is a hypothetical gravitational force carrying gauge boson It is not yet known if it exists m=0g (at rest), Ø≈0m, lifetime=∞, Q=0, Iz=2 Gravity The attraction between all the atomic particles in all matter due to their magnetic charges. Great Attractor The body of matter left over from after the last 'Big-Bang' that acts as a non-orbital force-centre slowing down the outward travel of galactic force-centres. Based upon a universal age today of 13.5 billion years and a current velocity of Hades of 600,000 metres per second, its mass is 2.1428862E+46 kg see The Universe see also ultimate body Guided Support A support that allows four degrees of freedom; lateral movement in both planes, axial movement and axial twist Hades The force-centre at the heart of our Milky Way galaxy has the following properties: Composition: mostly iron Density: 5300 < ρ < 8000 kg/m³ Mass: 1.76572E+41 kg Radius: ≈2E+12 m (based upon ρ = 8000 kg/m³) Spin-Rate: ≈2E-07 ᶜ/s (assuming 100bn star systems) see Dark Matter and The Universe Hadron 'ε' Is a bound state of quarks, which includes protons and neutrons There are two hadron sub-sets; baryons & mesons Half Life The time taken for a substance of same-elemental atoms to lose two neutrons from half of those with a neutronic ratio greater than 1. Head (liquids) The height of the surface of a liquid above a specified datum Heat Heat is electro-magnetic energy. "All heat is radiated": conduction is the radiation of electro-magnetic energy between adjacent atoms in both viscous and gaseous matter. Convection is the repositioning of atoms to balance proton electrical charges (eꞌ). Repositioning invloves hotter atoms moving further away from a source garavitational energy in order to minimise pressure. This is why heat always travels vertically upwards on the surface of the earth. Heat Capacity(Ct, Cᵥ and Cᵨ) The quantity of heat energy that can be absorbed by a given mass of substance per degree (temperature) This value varies with temperature Cᵥ = m.cᵥ Cᵨ = m.cᵨ where; m = mass Heat Capacity of an Electron: Cᵥ = 2.07097734E-23 J/K (constant volume) Cᵨ = 3.4516289E-23 J/K (contant pressure) Heat Capacity of a Proton (and a Neutron): Cᵥ = 3.80262743E-20 J/K (constant volume) Cᵨ = 6.3377124E-20 J/K (constant pressure) Cᵨ = Ct+Cᵥ The units of measurement are J/K, Btu/°R, W.s/K, N.m/K, lbf.ft/°R, etc. see Heat see also Ratio of Specific Heats Heat Energy(Q) The quantity of heat (energy) in a system at atmospheric pressure Q = Ṯ.Cp where; Cp = Heat Ṯ = temperature (absolute) The units of measurement are J, Btu, W.s, N.m, lbf.ft, etc. see Heat and Thermodynamics see also Specific Heat Capacity Heat Transfer Coefficient(U, h) The rate at which heat flows through a material or substance of specified thickness. Also known as 'Thermal Conductance' Heat Transfer Coefficientsin electrons(X, XR) {© 17/11/18} The rate at which electro-magnetic energy is converted into electron orbital velocity (and radius): Orbital Velocity (v): X = Ṯₙ/c² = 6.9353271647894E-09 K.s²/m² v = √[Ṯ/X] {m/s} Orbital Radius (R): XR = Ṯₙ.Rₙ = 1.75646616508035E-06 K.m R = XR/Ṯ {m} Heat Transfer Constant(Y) {© 17/11/18} Temperature constant used to define specific heat capacity of an atom: Y = ³√[½.ξᵥ] SHC = ΣKE / mₐ.Ṯ.Y where: ΣKE is the sum of the kinetic energy in all the electrons in an atom. mₐ is the mass of the atom. SHC is the specific heat capacity of the atom. Heat Transfer Rate(q) The rate at which heat flows from a material or substance of unit volume. Heave (vessels) The linear movement of a vessel in the direction of the vertical ('z') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Helical Gear A gear wheel, with teeth cut into its circumference in the form of a helix, that mates with another helical gear wheel The tooth profile is similar to that of a spur gear tooth The centres of rotation of two mating helical gear wheels are not necessarily parallel Henry(H) The unit of mutual inductance such that... the emf of one Volt induced in a circuit at one Ampere per second It can also be described as the rate of change current induced in an electrical circuit (C/s²) or in terms of energy as kg.m² / C² Hexagonal Close Packed(hcp) Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain twelve closely packed atoms, all of which are located at each corner of an hexagonal prism. This is the most closely packed of all the lattice structures. Heisenberg's Uncertainty Principle Higgs Particle 'ε' The Higgs particle is a very unstable boson with no spin, electric charge or color charge that almost immediately decays into other particles. It is a carrier of the Higgs field, which is supposed to give everything a mass component and without which all particles would simply be energy packets flying about at the speed of light. m≈2.246153801E-25g [≈126GeV/c²], Iz=0 Hooke's Law States that stress and consequent strain obey a linear relationship and that dimensional recovery is total when the material is relaxed This law applies to any elastically deforming body (e.g. a spring, a steel body, rubber band, etc.) all of which have a unique spring constant ('k') that defines the force needed to deform the body by one unit of length The units of measurement for 'k' are Force ÷ Distance {e.g. N/m or lbf/ft} see also Young's modulus Hoop Stress Primary circumferential stress in a pipe or cylinder Hydrocarbons Molecules comprising only hydrogen and carbon atoms Predominantly organic fluids (liquids and gases) originating from degraded and compressed animal and/or vegetable matter Includes; glycol, glycerine, benzene, propane, methane, ethylene, toluene, etc. Hydrodynamic Associated with the movement of water. Whilst the term 'hydro' refers specifically to water, hydrodynamic refereferences may be applied to the movement of any liquid. Hydrogen (atom)(H) Hydrogen is a collective term for four elements, all of which possess the same atomic number; Proton; H⁺ (a particle, not an atom ) Hydrogen; H (a proton-electron pair) Deuterium; D (H plus one neutron) Tritium; T (H plus two neutrons) 99.997% of all natural hydrogen is H⁺, which cannot exist in viscous form because they all possess an electrical charge of the same polarity (positive), and generate no magnetic field. Whilst 'D' and 'T' can (and do) exist in viscous form (e.g. in heavy water), it may be that at a sufficiently low temperature, the magnetic field generated by 'H' will be greater than the positive electrical charge in its proton, allowing it to exist in viscous form. Hyperbola The perimeter of any vertical plane through two inverted right-circular cones where; x²/a² - y²/b² = 1 eccentricity = √(1 + (b/a)² ) > 1 see Elliptical Curves see also Conic Hyper-Eutectoid A mixture of two metals that exist above their eutectoid state For example, an hyper-eutectoid steel is a mixture of pearlite and cementite; i.e. solid iron with > 0.83% carbon below 723°C Hypersonic Generally refers to a velocity more than twice Sonic; five times sonic is sometimes refered to as hypersonic. see also Subsonic, Supersonic, Transonic Hypocycloid (curve) A hypocycloid is a curve generated by a point on the circumference of a circle that is rolled around the inside of another circle without slipping. A curve generated by a point on the same circle but not on the circumference is called a 'Hypotrochoid'. Special Cases: The path generated by a point on the circumference of a rolling circle with ... ... half the radius of the stationary circle will be a straight line. ... a quarter the radius of the stationary circle is an 'Astroid'. see also Trochoid, Epicycloid and Cycloid Hypo-Eutectoid A mixture of two metals that exist below their eutectoid state For example, an hypo-eutectoid steel is a mixture of pearlite and ferrite; i.e. solid iron with < 0.83% carbon below 723°C Hypotenuse The side opposite the 90° angle of a right-angle triangle Hypotrochoid (curve) see Hypocycloid Hysteresis A loop showing a delay in the recovery of one property that varies as a result of varying another. A complete hysteresis loop is one where recovery catches up in each cycle (as shown in diagram). Ideal Gas A gas, the molecules of which, are of negligible size and do not interact chemically with each other. For example: nitrogen, argon, carbon dioxide, oxygen (O₂) and air are all ideal gases oxygen atoms (O) and ozone (O₂) are not ideal gases Also called a perfect gas Ideal Gas Law The mathematical relationship between the pressure, volume and temperature of a gas molecule: p.V = n.Ri.Ṯ where: 'p' is the pressure of the gas 'V' is the volume 'Rᵢ' is the gas constant. 'n' is the number of moles Impedance(Z) Impedance is the total electrical resistance in a conductor Impedance² = Reactance² + Resistance² Inductance (L) Inductance (the unit of measurement is the 'henry') is the resistance generated by the induced (or 'back') emf (electro-motive force), which opposes the applied emf and therefore retards the growth of an AC current It is this retardation of current flow by the induced emf that creates inductive resistance. Current lags voltage V = L.δI/dt where: V = voltage, I = current and t = time Induction(electrical) The transmission of electrical current between disconnected conductors via a magnetic field. Note: a current passed through a conductor will generate a surrounding magnetic field, & a magnetic field will induce a current in an encircled conductor. Inertia A body's resistance to a change in state of motion, which is a function of its mass Inertia is measured in units of mass, e.g. kg, lb, etc. Inertia Coefficient(Ci) A coefficient that represents the 'Added Mass' plus the mass of fluid displaced by the body itself Also known as Virtual Mass Inflammable In its strictest sense this means the inability to catch fire under any conditions, however, it is frequently used as an alternative for 'Flammable' CalQlata use this word to explain 'the inability to catch fire under any conditions' in the same way as incapacity means the inability to perform. see also Flammable Intensity (EME)(U) The number of EME emissions per unit area. Also known as EME density. Internal Energy(U) The energy in a system that has not been supplied from its surroundings. In a static system: U = Ṯ.Cv In a dynamic system: U = Ṯ.Cv + ½m.v² where; Cv = Heat (constant volume) Ṯ = temperature (absolute) m = mass v = velocity The units of measurement are J, Btu, etc. see Heat and Thermodynamics see also Specific Internal Energy Involute (curve) An involute is the curve generated by unwinding (straightening out) the arc (or circumference) of a curved shape such as a circle. For example: the end of a cotton thread unwound from a reel and pulled tight (straight) will describe a curve of ever-increasing radius as the unwound length of thread gets longer. The figure shows the involute of a circle, which can, for example, be represented by the path generated by the end of the a thread as it is unwound from a reel. The circumferencial length of arc ('A-O') is equal to the straightened out (unwound and tightened) length 'A-P'. The radius of the involute curve at any point is equal to the arc length of the circumference unwound. For example in the figure, the radius of the curve at 'P' is equal to the straight length 'A-P', which is also equal to the curved length 'A-O'. Involute curves are almost always used for the profile of gear teeth for the following reasons: 1) Mating teeth always share the load whilst engaged 2) Relative rates of motion between engaged teeth are constant and uniform 3) The line of action between teeth is always the tangent of a circle and therefore always acting perpendicular to the tooth surface 4) 1 to 3 above mean minimum wear and maximum load carrying capacity Ion The number of orbiting electrons in an atomic element relative to the number of protons in its nucleus. A positive Ion has fewer electrons than protons. A negative Ion has more electrons than protons. Ionic Bond Historic explanation: Ionic bonding [only] involves the complete transfer of valence electron(s) between metal and non-metal atoms. The metal atom loses electrons to become positively charged (cation). The non-metal atom gains those electrons to become negatively charged (anion). These opposite electrical charges are what subsequently holds these atoms together. For example: Na + Cl → Na⁺.Clˉ = Sodium & Chloride (salt) The greater the electrical polarity of each atom the greater the strength of the bond. Ionic bonds are generally stronger than covalent bonds. But bonds such as those in diamond (carbon) prove the exception is also true. However, there are no valencies in atomic electron shell's, so the above explanation is hypothetical. Ionic bonding is simply the sharing of electrion charges between adjacent atoms in viscous matter. Ionisation Energy Historic explanation: This term is used to describe the various energies required to isolate and attach sub-atomic particles (which do not exist), atoms and molecules. The term in CalQlata's Elements database refers specifically to the energy required to remove an electron from an atom's outermost shell. Ionosphere Stratum of the earth's atmosphere that contains only atoms and light ions of nitrogen and oxygen (Mesosphere to 600km) Temperature increases with increasing altitude Isentropic(thermodynamics) A process during which no change in entropy occurs i.e. whilst the temperature of a gas may change during a process, the heat energy (Q) available to do work remains the same; excess heat energy in a rising temperature process may be lost to the surroundings or other parts of the process, or; sufficient heat energy is recovered or added to a falling temperature process to maintain a constant amount available for work Isobaric(thermodynamics) A process during which there is no change in pressure I.e. whilst the volume and/or temperature of a gas in a system may vary, no resultant change in pressure will occur Isobaric refers only to the pressure properties of a process, it is therefore possible for a process to be isobaric and isochoric and/or isothermal Isochoric(thermodynamics) A process during which there is no change in volume I.e. whilst pressure and/or temperature of a gas in a system may vary, no resultant change in volume will occur Isochoric refers only to the volume properties of a process, it is therefore possible for a process to be isochoric and isobaric and/or isothermal Isosceles (triangle) A triangle with two of its sides of equal length and therefore, two equal angles Isothermal(thermodynamics) A process during which there is no change in temperature I.e. whilst pressure and/or volume of a gas in a system may vary, no resultant change in temperature will occur Isothermal refers only to the temperature properties of a process, it is therefore possible for a process to be isothermal and isobaric and/or isochoric Isotope Defined by the number of neutrons, relative to the number of protons, in the nucleus of an atomic element For example: Uranium 238 (U²³⁸) is an Isotope of Uranium (there are also 235, 236, etc. Isotopes of Uranium) but U²³⁸ is the most common U²³⁸ has 92 protons and 146 neutrons Isotropic A description of material proproperties that do not vary with direction, for example; the pressure in static fluid and elasticity, conductivity, permittivity, such as; in amorphous or multi-crystal materials e.g. steel, alloys, rock, plastic, rubber, glass, etc. Independent Wire Rope Centre A multi-stranded wire rope in which the core is an individual strand and not a fiber or polymer or single filament Jarno Taper A conical shaft and mating sleeve for machine-part self-holding applications that optimises assembly load, holding capacity and easy release (without damage). The tapered shaft is normally driven by an End-Tang (or Key) or a Longitudinal Key. You can have any size you like, but each taper is described dimensionally as follows, for example: Taper No. 7 Length=7÷2", Large Diameter = 7÷8",Small Diameter = 7÷10" Taper No. 12.35 Length=12.35÷2", Large Diameter = 12.35÷8",Small Diameter = 12.35÷10" etc. All tapers have a slope of 0.6 inches per foot (2.86419236832929°) The Jarno Taper is almost a direct alternative to the Morse Taper and used for similar applications to the Brown & Sharpe Taper Joule A measure of energy named after James Prescott Joule, who developed the theory of heat 1 Joule is the amount of energy expended by moving ... ... a force of 1 Newton over a distance of 1 metre or ... an electric charge of 1 Coulomb through a potential difference of 1 Volt Kepler'sLaws of Motion 1ˢᵗ An orbiting body follows the path of an ellipse 2ⁿᵈ Any two (or more) equal areas of elliptical orbits will be swept by equal periods of time 3ʳᵈ The square of the period of motion is proportional to the cube of the orbital semi-major axis see CalQlata's elliptical curves calculator and Laws of Motion KERS Kinetic energy recovery system. The conversion of Kinetic energy to electrical charge. This term is a bit of a misnomer: The formula for kinetic energy is ½.m.v² where 'v' refers to constant velocity but because velocity is constant, so is kinetic energy; there is nothing to recover. A KERS system converts energy during 'braking'; 'm.-a.d' where '-a' is deceleration, which is 'potential energy'. It could be said, however, that the process of deceleration is the 'shedding' of velocity, and it is this shed velocity (kinetic energy) that is recovered. But the process of shedding kinetic energy is actually potential energy, so the energy recovered and converted is actually potential energy. The correct term for this system should therefore be PERS Keulegan-Carpenter Number(K) Flow parameter associated with the drag of a fluid over an object. K = Uₘ.t / D Where Uₘ = velocity amplitude t = period of flow D = relevant dimension (e.g. diameter of a pipe or thickness of an airfoil) Kinetic Energy(Uᴷ & KE) Energy possessed by a moving body Linear: Uᴷ = ½mv² ÷ gc Rotational: Uᴷ = ½Iω² ÷ gc Where: v = velocity of the body ω = rotational velocity (ᶜ/s) m = mass of body I = moment of inertia gc = gravitational constant (dimensionless) Laminar Flow A fluid that flows perfectly smoothly generating no disturbance or mixing of adjacent layers Lang Lay A particular type of helical lay pattern in a wire rope where the filaments are wrapped within each strand in the same helical direction as the strands are wrapped within the wire rope. In a manufactured wire rope, the filaments run at an angle (diagonal) to the long axis of the wire rope (see image). You can have 'right Lang lay' or 'left Lang lay' configurations: In a 'right Lang lay' configuration the strands follow the same helical direction as a right-hand screw thread(see image) In a 'left Lang lay' configuration the strands follow the same helical direction as a left-hand screw thread(opposite to image) Lang lay wire ropes provide excellent wear resistance when used with a sheave (or pulley) due to their smoother (flatter) surface and high bending fatigue resistance but suffer from birdcaging if ill used. They are generally used for specialist applications where repeated bending and wear resistance is an issue but structural stability is not. see also Regular Lay Latent Heat The heat required to change a substance from one state to another with no resultant change in temperature For example; latent heat of vaporisation is the heat required to convert a liquid into a gas Lateral see Latitudinal Lateral Stress Primary stress at right-angles to the axis of a component Latitude(Lat) The horizontal grid-lines that divide the surface of the earth into 180 unequal spherical segment zones (slices) The vertical distance between each gridline at the equator = 111319.8922m The vertical distance between each gridline at the poles = 110963.0597m The surface area between two gridlines at the equator (0° & ±1°) = 4.46094E+12m² The surface area between two gridlines at the poles (±89° & ±90°) = 7.7361644E+10m² Latitudinal 1-D distance or movement across the width of a body or shape; normal to its longitudinal line or axis. For a sphere; this refers to the shortest distance between two points over its surface; normal to its longitudinal lines. see also Longitudinal Lattice Structure(metals) General term referring to the structural arrangement of 'same-element' atoms in their lowest energy state, which applies to both their viscous and their gaseous conditions. The lattice structure of an atom is defined by the structure of its atomic nucleus. Latus Rectum The width of an elliptical curve (2p) at its focus (F) Also called the parameter of the curve see also Ellipse, Hyperbola and Parabola Lens A device that converges electromagnetic waves (radiation) at a focal point# A lens may converge or diverge the radiation dependent upon the path of the light-ray in relation to the convex or concave nature of the lens faces. The front of the lens is the face at which the radiation enters the lens The back of the lens is the face at which the radiation exits the lens # The generally accepted position of the focal point of a spherical lens is theoretical (see Focal Length). Lepton 'ε' A family of sub-atomic particles within the fermion group There are 6 leptons (Iz isospin quantum number); electron(-½) & electron neutrino(½) muon(-½) & muon neutrino(½) tauon(-½) & tauon neutrino(½) Lift Coefficient(Cʟ) A coefficient used to define the lateral force (or lift) developed in a beam or structure as a result of a fluid passing along or across it at 90° to the direction of lift This coefficient varies between 0 and 4, and is dependent upon the Keulegan-Carpenter number, which must be 0 > Kc > 130 for lift to occur Maximum lift force occurs when Kc ≈ 12 Light (visible) The visible [to the animal kingdom] range of Electro-magnetic energy Ranges from: ultra-violet > infra-red 1.0E-08m<λ<0.001m (3.0E+16Hz>ʄ>3.0E+11Hz) The speed of light (c) in free-space (a vacuum) is defined as: c² = 1 / ε₀.μ₀ c = 299792458m/s (6.70616632E+008 mi/h) All Electro-magnetic energy travels at this speed, irrespective of frequency or wavelength This value was fixed by convention as a result of declaring one meter as the distance traveled by a specific light source# in a vacuum in 1/299792458 seconds (CGPM Oct/1983) and is therefore considered to be exact. Linear Expansivity(α) Linear Acceleration(a) The acceleration of a point travelling in a straight line see also Angular Acceleration and Rotational Acceleration Linear Velocity(v) The velocity of a point travelling in a straight line see also Tangential Velocity Liquid Matter in a viscous state but at a temperature whereby inter-atomic magnetic field strength is less than gravitational force, allowing adjacent atoms to move with no outside assistance. This is a low temperature condition. Liquidity is a relative term, it describes the ability of viscous matter to resist shear forces; or lattice plane slip. Liquid state refers to low viscosity. # see State of Matter see also Solid and Gas Locus The path generated by a point following a mathematical equation. for example: the locus of a point 'x,y' following the equation: r² = (x - a) + (y - b)² will draw a circle of radius 'r' centred at position 'a,b' Logarithm(log, log₁₀) The logarithm value of a number The logarithmic base may be any positive number but is usually 10 see Logs and Trig-technical help see also Natural Logarithm Longitude(Lon) The vertical (pole to pole) grid-lines that divide the surface of the earth into 360 equal spherical wedges (1°) 0° & 360° gridlines run through the Royal Observatory at Greenwich, England (see internet for John Harrison) The horizontal distance between each gridline at the equator = 111319.8922m The horizontal distance between each gridline at the poles = 0m The surface area between two gridlines = 1.41548E+12m² Longitudinal 1-D distance or movement along the length (long-axis) of a body or shape. For a sphere; this refers to the shortest distance over its surface between its poles. see also Latitudinal Longitudinal Stress Primary stress parallel with the axis of a component Lorentz's Magnetic Force Lorentz defined the force between two magnets thus: F = q.(Eₒ + v.B) where: F = force q = electrical charge Eₒ = initial electrical field v = velocity B = magnetic field His formula actually distils down to: F = e.v² / R.RC (dynamic) or F = e.a / RC (quasi-static) where: R = radial separation a = [magnetic or gravitational] acceleration between magnetic particles Mach [number](M) Ernst Mach's ratio of the velocity of a fluid and that of a sound passing through it. Magnetic Constant(μ₀) The permeability of free space (a vacuum) μ₀ = 4.π.μ H/m {kg.m / C²} where: μ is the fundamental magnetic constant: μ = mₑ.Rn/e² kg.m/C² = 1E-07 {exact} Magnetic Charge The non-polar magetism held by all atomic particles. It is the source of magnetism and gravity Magnetic Field(B) A region around an electro-magnetic charge within which a magnetic force acts B = μₒ.I / 2.π.R {kg / C} Where: R = the distance between the electro-magnetic charge and the magnetic force. Within an atom: B = 1/RC (B = 5.685634367312E-12 kg/C) where: R = 2.Rₙ Magnetic Flux(Φ) The magnetic equivalence of electrical current. Where: Φ = mmf/Reluctance. Magnetism The attraction between metals due to the alignment and proximity of the magnetic charge in their atomic particles. Some magnetic materials are listed below: Iron: The most common magnetic material Neodymium: The strongest of all permanent magnets Cobalt: Highest curie point Gadolinium: Curie point at room temperature Terbium: Changes shape in a magnetic field Dysprosium: Alloying element for special magnets Magnetic Quantum Number(m) 'ε' The third in a set of quantum numbers that describes the energy level of the electron The magnetic quantum number of an electron can be a positive or negative integer: i.e. -5, -4, -3, -2, -1, 0, 1, 2, 3, 4, 5, etc. The magnetic quantum number must be different for each electron in the same shell with the same azimuthal and spin quantum numbers Magneto-Motive Force(mmf) The work done to premeate magnetic flux through a closed magnetic circuit. The magnetic equivalent of 'emf'. Marageing An ageing heat treatment procedure used to harden, strengthen & toughen certain alloys (most alloys do not respond to this process). The age hardening process is performed as follows: The alloy is quenched from a suitable temperature (e.g. 500°C for Duralumin) and then left at room temperature for about a week. This process can be accelerated in some alloys by increasing the storage temperature from ambient to about 180°C A marageing alloy can therefore be machined or formed easily and subsequently strengthened with age over a very short period. The word originates from 'mar' for martensite (the steel structure) and 'ageing' to describe the process It is frequently spelt 'maraging' by misspelling 'ageing' as 'aging' Martensite Super saturated austenite created by rapid cooling (quenching). Carbon exists in sharp clumps between the grains of iron making it hard and brittle. Tempering after quenching allows the excess carbon to form smaller spheroids and redistribute itself reducing hardness and brittleness Mass The quantity of matter in a body equivalent to its inertia and is measured in kg, lbs, etc. The mass of a body is equal to: a) its weight divided by the coincident gravitational acceleration and b) its density multiplied by its volume This property for any given body remains the same irrespective of liquifaction, dissection and location (in the iniverse) Matter A collective expression for all forms of substance, including both viscous and gaseous. Maximum Metal Condition(MMC+) The condition of at least two assembled components that when machined within required dimensional tolerances results in the removal of the least material Whilst convention does not differentiate between minimum and maximum metal conditions when using the symbol 'MMC', CalQlata always uses MMC+ for this condition see Symbols Mechanical Equivalent of Heat(J) A conversion factor for heat energy and work energy see calorie and Btu. Calculations using metric units;J = 1.0 Calculations using Imperial units;J = 4.18542247371685 J/cal = 777.913151806073 ft.lbf/Btu Median A straight line that joins a vertex with the centre of the opposite side Medium The substance of an environment, e.g.; an aircraft's medium is the earth's atmosphere a submarine's medium is the earth's oceans (seawater). Member A longitudinal component such as a structural element, rod, bar or beam Membrane A large plate or sheet of thin material than can comprise any natural or manufactured matter see also diaphragm Membrane Stress Tensile or bending stress in the flat plane of a membrane see also Membrane Meson 'ε' A pair of sub-atomic particles comprising one quark and one anti-quark (part of the Hadron particle family) Mesosphere The ceiling for 99.95% of nitrogen, the earth's most abundant atmospheric gas (Stratosphere to 80km) Stratum of the earth's atmosphere that comprises the ceiling of normal atmospheric gases (see Ionosphere) Temperature reduces with increasing altitude Metacentre The point at which a vertical line passing through the centre of buoyancy of a slightly tilted vessel meets a line through its centre of gravity (see image). Metacentric height:the vertical distance between the centre of gravity of a vessel and its metacentre The vessel is stable if the metacentre is above the centre of gravity and unstable if it is below. A vessel's stability is defined by the metacentric height.The greater the height the more stable the vessel. Metallic Bonds Metallic elements lose electrons freely generating a cloud or sea of electrons in which positively charged metal atoms (cations) are held together. Metallic bonds tend to be the easiest to form and also the easiest to break, making metals the most versatile of the elements. see also Covalent and Ionic bonds Microstate(N) The volumetric, pressure and heat energy states of atomic particles governed by the relationship: cᵨ.Ln(Ṯ).RAM = Rᵢ.Ln(N) volumetric: Nᵥ = cᵥ/Rₐ pressure: Nᵨ = cᵨ/Rₐ heat: Nt = exp(Nᵨ.Ln(Ṯ)) Minimum values: Nᵥ = 1.5 Nᵨ = 2.5 Nt = 1 see Heat Microwaves Long wave electromagnetic radiation that falls between infra-red light and radio-waves Ranges from: 0.001m<λ<0.1m (3.0E+11Hz;>ʄ>3.0E+09Hz) Minimum Metal Condition(MMC-) The condition of at least two assembled components that when machined within required dimensional tolerances results in the removal of the most material Whilst convention does not differentiate between minimum and maximum metal conditions when using the symbol 'MMC', CalQlata always uses MMC- for this condition see Symbols Mode The beam length deflected between two nodes see also Amplitude Modulus of Elasticity(E) The measure of a substance's ability to resist deformation under pressure (or stress) and return to its original shape when the pressure (or stress) is released. Also knowmn as elastic modulus and Young's modulus the general formula for this property is; E = stress ÷ strain see also bulk modulus, elastic modulus and rigidity modulus Modulus of Rigidity(G) The measure of a substance's ability to resist deformation under a shear force and return to its original shape when the shear force is released. Also knowmn as shear modulus Whilst this is also a measurement of elastic modulus, the strain in this case is modified by the shear angle. the general formula for this property is; G = E ÷ 2.(1+ν) see also Shear Stress Modulus of Shear Molarity The number of moles of an ion per litre of solution Mole The mass of a material that contains Avogadro's number of particles (atoms, molecules, etc.) For example; One mole of carbon (12.01 RAM) contains 5.97538412973187E+23 atoms and weighs 12.01g One mole of a substance, also containing 5.97538412973187E+23 atoms, with three times the relative atomic mass of carbon '36.03 RAM' (3 x 12.01) will therefore weigh 3 times as much as carbon, i.e. 36.03g see also Avogado's number Molecular Density The mass density (g/m³) of a substance divided by its relative atomic mass (g/mole) ρᴹ = ρ ÷ RAM (moles/m³) see also Molecular Weight Molecular Weight The sum of relative atomic masses comprising a molecule For example: The molecular weight of water (H₂O): 2 x 1.00794 + 1 x 15.9994 = 18.01528 (dimensionless) This calculation can also be applied to a mixure of gases (i.e. not a molecule) in order to specify its molecular weight For example: The molecular weight of air (excluding trace elements): N₂ (78.087%) RAM: 28.0134 = 0.78087 x 28.0134 O₂ (20.95%) RAM: 31.9988 = 0.2095 x 31.9988 Ar (0.93%) RAM: 39.948 = 0.0093 x 39.948 CO₂ (0.03%) RAM: 44.0095 = 0.0003 x 44.0095 RAMₐᵢᵣ ≈ 21.875 + 6.704 + 0.3715 + 0.0132 ≈ 28.9633 Note: including all trace elements RAMₐᵢᵣ = 29.32406451 Molecule The smallest part of a substance that exhibits its chemical properties. A molecule is at least two electrically charged ions joined together via ionic or covalent bonding. Moment(M) An applied load or centre of area a given distance from a datum Also known as torque or rotational moment or bending moment or area moment Moment Couple Two parallel opposing forces applied a specified distance from each other Moment of Inertia(I)(of an area) Also (incorrectly) known as second moment of area, describes the mass of a body about its neutral axis That is, the sum of all the particle masses multiplied by the square of their distances from the neutral axis (radii of gyration) I = A.ɍ² Moment of Inertia(I̊)(rotational) Inertia possessed by a body rotating about a central axis I̊ = m.ɍ² Momentum(p) A quantity of straight-line motion of a body equal to its mass multiplied by its velocity; p = m.v (kg.m/s) Also a measure of force (m.a) multiplied by its period of application (in seconds); p = t.m.a (s.kg.m/s² = kg.m/s) Monoclinic The arrangement of atoms within the shape of a single metal crystal. This crystal shape is a single atom located as close as possible to its neighbour. Monatomic (gas) A gas (mixture or pure) comprising only single atoms, such as argon, radon, helium, neon, etc. Morse Taper A conical shaft and mating sleeve for machine-part self-holding applications that optimises assembly load, holding capacity and easy release (without damage). The tapered shaft is normally driven by an End-Tang (or Key) or a Longitudinal Key. Different size numbers (0 to 7) relate to different engaged lengths (1-15/16" to 9-1/2") Morse's nominal included angle is 2.86419236832929° However, as each size is based upon standard fractional lengths and diameters, not all tapers (0.05 and 0.052 inches per inch) will have exactly the same angle (2.86° to 3.0°) The optimum angle for a coefficient of friction of 0.8 for clean, dry, ground, carbon steel surfaces is 2.9745503204919° The Morse Taper is a direct alternative to the Jarno Taper and used for similar applications to the Brown & Sharpe Taper Most Damaging Stress-Block The stress-block that lies closest to the S-N curve, within a group of stress-blocks that together constitute the fatigue life of a material or mechanical component Motor A motor uses magnets and coils of copper wire to convert AC or DC electricity into rotary motion. see also Alternator and Motor Multi-Phase(fluid flow) The flow of more than one category of fluid. Normally applied to the flow of fluids through a pipe in the petroleum industry; where a multi-phase fluid comprises at least two of the following: Oil and/or water and/or gas multi-phase also includes the flow of entrained solids (such as sand) if present. see also Single-Phase Muon 'ε' An elementary particle similar to the electron (also with a negative electric charge) but much heavier A muon is classified as a lepton m=1.884273466E-25g [105.7MeV/c²], lifetime=2.2μs Natural Frequency(ƒⁿ) see Frequency Natural Period see Frequency Nappe (conic) One of two sheets on either side of the vertex forming a cone Natural Logarithm(Ln, logₑ) The logarithm value of a number, the base of which is 2.71828182845905 see also Logarithm Necking(plastic deformation in metals) The reduction in cross-sectional area of a metal object exposed to a tensile stress greater than UTS but less than breaking stress Neutral Axis The plane through a bending body in which no tension or compression occurs Note: tension occurs in the material on convex side of the neutral axis and compression occurs in the material on concave side Neutrino 'ε' An elementary particle with minuscule but nonzero mass that often travels close to the speed of light, that lacks an electric charge and is able to pass through ordinary matter almost undisturbed and are thus extremely difficult to detect A neutrino is classified as a lepton Neutrinos are created as a result of certain types of radioactive decay or nuclear reactions such as those that take place in the Sun, in nuclear reactors, or when cosmic rays hit atoms. There are three types, or "flavours", of neutrinos: electron neutrinos, muon neutrinos and tauon neutrinos; each type also has an antimatter partner, called an anti-neutrino. Electron neutrinos or anti-neutrinos are generated whenever neutrons change into protons or vice versa, the two forms of beta decay. Interactions involving neutrinos are generally mediated by the weak force Neutron {© 01/10/18} An electrically neutral atomic particle that comprises a proton and an electron that united at the neutronic temperature. This event occurs when the electron is orbiting at the neutronic radius, which is achieved when it reaches light-speed (PE=mc²). Neutrons are only created within, and can only exist within, an atomic nucleus. And they are only released from their nucleus after they have been split into their component parts. mass; mₙ = mₚ + mₑ = 1.6735325768E-27 kg radius; rₙ = 1.77645508248591E-15 m see The Neutron see also Neutron Decay Neutron Decay {© 01/10/18} The revertion of neutrons to their original alpha and beta particles. This event occurs in all atoms with a neutronic ratio greater than 1.0 but increasing in frequency with increasing neutronic ratio. see The Neutron Neutron Energy {© 01/10/18} Every neutron holds the same potential, kinetic and spin energies its proton-electron pair was generating when it was created: Potential Energy; PE = -mₑ.c² = -8.18711122262534E-14 J Kinetic energy; KE = ½.mₑ.c² = 4.09355561131267E-14 J     Proton spin energy; SEₚ = KE+PE = -4.09355561131267E-14 J     Electron spin energy; SEₑ = ½.J.ω² = 4.33820131944073E-17 J Spin Energy; SE = |SEₚ+SEₑ| = 4.09789381263211E-14 J E = |PE| + |KE| + |SE| = 1.63785606465701E-13 J. see The Neutron Neutronic Radius(Rn) {© 01/10/18} The orbital radius that an electron will achieve when it reaches the speed of light due to the neutronic temperature, i.e. when the attractive magnetic charges exceed the repulsive electrical charges. This is when the electron will combine with its proton to create a neutron Rn = h.vo/Ee = 2.81793795383896E-15 m where: minimum orbiting electron velocity; vo = 174090.866621083 m/s kinetic energy of an electron at light-speed (½mec²); Ee = 4.09355561131268E-14 J Neutronic Ratio(ψ) {© 01/10/18} The ratio of neutrons to protons in an atomic nucleus; ψ = RAM/Z-1 Neutronic Temperture(Ṯn) {© 01/10/18} The temperature required to drive an orbiting electron at the speed of light and the neutronic radius, i.e. when the attractive magnetic field energy generated by the two particles exceeds the repulsive energy generated by electrical charge. This is when the electron will combine with its proton to create a neutron Ṯn = 623316124.717178 K Newton's Atom {© 01/10/18} Newton's atomic values are calculated below: Newton's time; t = 2π.λ = 1.76514516887831E-19 s Newton's length; λ = aₒ = 5.29177210670000E-11 m Newton's mass; m = mN = 7.12660796350449E+16 kg Newton's energy; E = m.c² = 6.40507585675677E+33 J Newton's force; F = E/λ = 1.21038391820525E+44 N all the above have been derived by CalQlata where: mN = Newton's mass c = speed of light in a vacuum Newton'sForce Law The potential (gravitational) force between any two bodies of mass (m₁ & m₂) separated by distance 'R'. F = G.m₁.m₂ / R²) Newton'sLaws of Motion 1ˢᵗ Every mass retains its momentum (including rest) until a force acts upon it (Galileo's law of inertia) 2ⁿᵈ A change in momentum is proportional to, and acts in the direction of, the applied force 3ʳᵈ To every action there is an equal and opposite reaction Newton's Mass(mN) Unit mass of ultimate density mN = aₒ.c² / G = 7.12660796350452E+16 kg see also Proton and Electron Nobility(noble metals) Describes the chemical stability of a metal. The more noble a metal (e.g. gold, silver, platinum, etc.) the less chemically active it is. The least noble metals, which include caesium, sodium and magnesium are all highly reactive. A noble metal is electrically positive; i.e. it has a high affinity for electrons (see electronegativity). As a rule, the higher the electronegativity of a metal, the more noble it is. Therefore, whilst electronegativity cannot be used as a measure of nobility it may be used as a guide. Nodal Points(of a lens) Two points on the axis of a Lens such that an entering ray of light would theoretically project through to one nodal point (ignoring refraction) and appear to exit the lens from the other nodal point, parallel to the entering ray. The angle at which a such a light-ray must enter the lens varies with its radial distance from the lens axis and only occurs at radii close to it. The primary nodal point refers to the point at the front of the lens The secondary nodal point refers to the point at the back of the lens As the radial distance (from the lens axis) of the entering light-ray tends towards zero, the nodal point (primary or secondary) of a lens will coincide with the associated principal point if the refractive index of the environments are identical both sides of the lens. Node The points of intersection at each end of a mode Non-Polar All-pervasive: acts in all directions at the same time see also Polar Normal(angular) 'Normal to' is an expression used to describe the relationship of one direction being at right angles to another Normalise(carbon steel) To normalise a steel alloy is to optimise its strength by heat treatment without making the material hard (brittle). Carbon steel is normalised by heating it above 723°C, holding it there to allow all the material to transform to austenite and allowing it to cool naturally in still air, i.e. more quickly than annealing. Nucleus(atomic) The proton partners of all the proton-electron pairs comprising an atom, together with their attached neutrons, which may be one or two per proton-electron pair. The structural arrangement of the atomic nucleus will define the lattice structure of the same atoms in both gaseous and viscous conditions. Oblique An angle that is not equal to 90° Oblique (triangle) A triangle in which none of the angles equal 90° Oblong A three-dimensional, six-sided figure, each side of which is 90° to its adjacent sides see also Rectangle Obtuse (angle) An angle between 90° and 180° Open Hearth The Open Hearth is a process for making steel (it is also called the Siemens-Martin process). It directs the waste heat given off by the furnace through an open firebrick lining, heating the brick-work to a very high temperature. The same pathway is also used for introducing preheated air into the furnace significantly increasing the melt temperature. This process is gradually replacing the Bessemer Converter. Orbit A curved (e.g. elliptical) path generated by a body travelling around a central point that is maintained by equal and opposite centripetal and centrifugal forces Fᵖ = m.g = ½.m.v² / r i.e. g = v² / 2.r and r = v² / 2.g where 'r' is the natural orbital radius of any given orbiting mass travelling around a central mass at a given velocity Elliptical orbits are maintained by the gravitational (potential) energy (PE) between a satellite and its force-centre, which induces the kinetic energy (KE) in the satellite. In elliptical orbits; PE < -2.KE Circular orbits are maintained by the gravitational (potential) energy (PE) between a satellite and its force-centre, and the satellite's intrinsic kinetic energy (KE). In circular orbits; PE = -2.KE Order(thermodynamics) see Disorder Overpressure A pressure higher than ambient It is normally measured in multiples of unit ambient pressure such as bar or atmospheres, e.g... 10 tam (or 10 bar) is 10 times as high as ambient pressure Ozone Oxygen molecules (O₂) are split apart by the sun's ultra-violet light radiation and the two resultant oxygen atoms then bond to other oxygen molecules to produce ozone (O₃). Ozone is unstable and converts back to oxygen molecules as it falls into the troposphere where it reacts with other gases. see Ozone Layer for an explanation of the 'hole'. Pappus theorum The calculation of volumes by rotating an area about a central axis E.g. V = 2πRA where; V is the volume of the swept area A is the rotating area R is the radius from the centre of gravity of final volume to the centre of area (A) Parabola The perimeter of any plane cut through a right-circular cone parallel to its slope where; y² = 2.p.x eccentricity = 1 see Elliptical Curves see also Conic Parallel Two infinitely long 1-D or 2-D shapes that will never converge irrespective of their proximity. Parallelepiped Any three-dimensional figure with six faces, four of which are dimensionally equal and parallel and the two ends are also parallel and dimensionally equal. Also described as a three dimensional rectangle of constant thickness. A special Parallelepiped is a cube where all 6 faces are dimensionally equal. Parallel Lay(wire rope) All strands are wrapped parallel to each other, i.e. in the same helical direction Paramagnetism The attraction of a non-magnetic material towards a magnet (magnetic attraction tends to be weak) Paraxial(lens) A ray of light travelling towards the front face of a lens very close to its axis and parallel to it. Partial Pressure The pressure of each gas occupying a space or container in a mixture of fluids see Partial Pressure-technical help see also Dalton's Law Particle The smallest constituent part of an atom: an electron, a proton or a neutron see also Quanta Pauli's Exclusion Principle 'ε' Only one fermion can occupy a quantum state at a given time Therefore if more than one fermion occupies the same place in space, the properties of each fermion (e.g. its spin) must be different from the rest Pearlite Alternate layers of cementite and ferrite generated as austenite containing 0.83% carbon cools below 723°C Pearlite contains the same amount of carbon as the maximum carbon carrying capacity austenite (0.83%) Perigee The nearest point an orbiting body gets to its attracting mass Whilst this term can also be used instead of Perihelion (i.e. it means the same thing), it is normally used to describe the point at which the distance between earth and its orbiting moon is smallest This term is made up of the Greek prefix peri for 'around' or 'about', and the Greek word gee for the earth. a = half the width of the elipse e = its eccentricity see also Aphelion and Apogee Perihelion The nearest point an orbiting body gets to its attracting mass Whilst this term can also be used instead of Perigee (i.e. it means the same thing), it is normally used to describe the point at which the distance between sun and its orbiting planet is smallest This term is made up of the Greek prefix peri for 'around' or 'about', and helion from 'Helios' the Greek sun god. a = half the width of the elipse e = its eccentricity see also Aphelion and Apogee Permeability(μ) The ratio of magnetic flux density in a medium to the magnetising force producing it. The permeability of free space (i.e. in a vacuum) is the Magnetic Constant Permeance(magnetism)(P) A measure of the ability for magnetism to permeate a substance. The reciprocal of magnetic reluctance (1/S). Permittivity(ε) The ratio of electric displacement in a medium to electric field intensity producing it. also called dialectric constant or specific inductive capacity The permittivity of free space (i.e. a vacuum): ε₀ = 1 / μ₀.c² = 8.85418775855161E-12 C²/m / J Because the speed of light in a vacuum and the magnetic constant are both considered to be exact values, this too is considered to be an exact value. Perpendicular At 'a right angle' or '90°' or 'normal' to a line or surface PERS Potential energy recovery system. The conversion of potential energy to electrical charge. This system is today known as KERS. The formula for potential energy is m.-a.d where 'm' = mass; '-a' = deceleration; 'd' = distance and it is this [potential] energy that is recovered and converted to electrical charge. Phase Angle (electrical) The angle of shift between the alternating current and the voltage in an AC power supply. As the current in an inductive AC power supply will peak after the voltage, it is said that the current 'lags' the voltage. As the current in a capacitive AC power supply will peak before the voltage, it is said that the current 'leads' the voltage. If there is only inductive or capacitive resistance in an AC power supply, i.e. there is zero resistance in the conductor, the phase angle will be 90°. If there is no inductive or capacitive resistance in an AC power supply the phase angle will be 0°. Electrical resistance in the conductor will shift the phase angle between 0° and 90°. The Arccosine of this 'Phase Angle' is the Power Factor of the supply. see also Apparent Power and True Power Phase Diagram An equibrium diagram of an alloy metal that defines the natural crystal structure of specific alloy compositions at specific temperatures. Also called an equilibrium diagram. Photon 'ε' An electron that emits electromagnetic radiation (light) equal to Planck's constant multiplied by its frequency In this case; frequency = speed of light (c) ÷ wavelength of the photon (λ) A photon is a Gauge Boson m=0g, Ø≈0m, lifetime<10¹⁸yrs, Q=0, Iz=1 All of which is fiction. Electrons do not emit light (see Quantum Theory is Dead). pi (π) The ratio between a circle's circumference and its diameter π is an infinitely long number that can be calculated from the series formula: π² = 6/1² + 6/2² + 6/3² + 6/4² + ..... However, you would need to include a lot of terms to obtain an accurate value for π using this method as the inclusion of even 100,000 terms only reaches a value of 3.14158310432644 CalQlata uses the value of 3.14159265358979 in all its calculators. Pinned Support A simple support on a beam Pipe A tube or cylinder with a length greater than ten times its diameter. Pitch (vessels) The rotational movement of a vessel about the lateral ('y') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Planck's Constant(h) Planck's law states that the energy of an electromagnetic wave is confined to indivisible packets (quanta) each of which has to be radiated or absorbed as a whole and the magnitude of this energy is proproportional to its frequency. If E is the energy (J) and ƒ is the frequency of the electromagnetic radiation (/s) then: h = E/ƒ = E.λ / c = E / Rᵧ.c = √(π.mₑ.e².aₒ / ε₀) h = 6.62607174469163E-34 kg.m²/s However, the units achieved by his formula and those he claimed for it; 'J.s', are incompatible; a ratio of frequencies is missing. The correctd version of Planck's constant is: h' = 1.15353857232684E-28 kg.m³/s² {and his units are; 'J.m'} (see Magical Constants; §7 to §12) see also Planck's Atom Planck's Atom Planck's atom comprises three values he defined; time, length and mass, each of which is calculated as follows: Planck's time; t = (ħ.G / c⁵)⁰˙⁵ = 5.39096122598358E-44 s Planck's length; λ = (ħ.G / c³)⁰˙⁵ = 1.61616952231127E-35 m Planck's mass; m = (ħ.c / G)⁰˙⁵ = 2.1765500017459E-08 kg CalQlata has expanded the above as follows: Planck's energy; E = (ħ.c⁵ / G)⁰˙⁵ = 1.95618559889903E+09 J © Planck's force; F = c⁴/G = 1.21038391820525E+44 N © where: ħ = Dirac's constant G = Gravitational constant c = speed of light in a vacuum Planck's atomic particle: radius = 5.07563837996471E-16 m © volume = 5.47722557505167E-46 m³ © mass = 2.1765500017459E-08 kg (see m above) density = 3.97381844498046E+37 kg/m³ © force between Planck's atomic force-centre and satellite ©    = 1.21038391820525E+44 N (see F above) Plastic Strain A material that does not return to its pre-deformation dimensions when stress is released (i.e. does not obey Hooke's Law) Plow Steel A high quality, high strength carbon steel (0.5% to 0.95%) used to manufacture 'Bead Wire' Point Load An applied force that is concentrated at a single point Poisson's Ratio(v) The relationship between axial stress and the lateral deformation when applied to a body that obeys Hooke's Law;where v = (E / 2.G) – 1 Poisson's ratio varies in magnitude between 0 for a totally brittle body (no deformation whatsoever) and 0.5 for a perfect elastomer (same deformation in all three directions). 0.3 is normally used for carbon steel Polar Unidirectional: acts in a straight line see also Non-Polar PolarCo-Ordinates The directional definition of a vector using its angular relationship to 2-D (α,r) or 3-D (α,β,r) axes see also Cartesian Co-Ordinates and Vector Polar Moment of Inertia(J) Describes the structural strength of a cross-sectional area, or a numerical representation of its resistance to torsional deformation It also describes the rotational moment of inertia of a solid shape {kg.m² or lb.ft²}, e.g. of a cylinder or sphere The polar moment of inertia of any shape is the sum of any two second moments of area (of the same shape) at 90° to each other Note: The sum of any two moments of inertia at 90° to each other of any shape will always be equal to the sum of any other two moments of inertia at 90° to each other for the same shape and about the same centre of rotation, irrespective of their relative orientation Polygon A 2-D shape with three or more sides A Regular polygon has equal sides and an irregular polygon has unequal sides Polytropic(thermodynamics) A process in which the relationship between pressure, volume and ratio of specific heats of an ideal gas in a system remain constant and can be defined thus: p.Vn = K Where: p is the pressure of an ideal gas V is the volume of the system K remains constant for all stages of the process n varies with the type of process, e.g.:    Isothermal; n = 1    Isentropic; n = γ (specific heat ratio)    constant pressure; n = 0    constant volume; n = ∞ Positron 'ε' A positive electron of the same mass and electrical charge (but opposite sign) as an electron Positrons are produced in the decay of radio-isotopes and X-rays of energy greater than 1MeV Potential-Difference(PD) The electrical difference between two discrete points generated by an electro-motive force The unit of measurement is a Volt which equals one Joule of work done by one coulomb moving between them Potential Energy(Uᴾ & PE) The energy stored in a system or body It could be stored in a compressed (or stretched) spring:Uᴾ = ½ky² ÷ gc or It could be stored in a body raised above the ground:Uᴾ = mgh ÷ gc Where: k = spring constant (see Hooke's Law) y = deformation of spring m = mass of body g = gravitational acceleration h = distance from point of impact (e.g. height above ground) gc = Gravitational Constant (dimensionless) Potential-Hydrogen(pH) Potential Hydrogen (sometimes referred to as the 'power of hydrogen') defines the positive hydrogen ion activity in a solution Low hydrogen activity means the +ve Hydrogen ion (H+) molarity of a solution is less than 10⁻⁷ and is said to be acidic (pH<7) The +ve Hydrogen ion molarity of a neutral solution (e.g. pure water) is 10⁻⁷ (pH=7) High hydrogen activity means the +ve Hydrogen ion (H+) molarity of a solution is more than 10⁻⁷ and is said to be alkaline (pH>7) pH can be calculated using the following formula: pH = -Log₁₀(aH+) or Log₁₀(1/aH+); where aH+ is the +ve hydrogen ion molarity of the solution (i.e. the number of moles of H+ ions in one litre of the solution; 'a' represents the atomic element(s) attached to the H+ e.g. OH₃ is an aH+ ion) Power The rate at which energy (or Work) is expended. The faster work is done, the more power is consumed The units of measurement are; Btu/h, W, J/s, cal/min, N.m/s, lbf.ft/min etc. Power(of a lens) The reciprocal of the focal length (ƒ) of a lens P = 1/ƒ Power Factor (electrical) The factor applied to the Apparent Power of an alternating circuit in order to convert it into True Power It is calculated thus: p.f. = Resistance ÷ Impedance and is the cosine of the Phase Angle between the alternating current and the alternating voltage. Pressure A force applied over an area. Pressure Vessel An enclosure of any shape that will contain or resist a fluid under pressure without leakage Thin-wall vessel: t < Ø÷10 Pressure Welding Press two or more metals together with sufficient presssure to cause metal fusion between them. This process may be carried out at an elevated temperature to assist the welding process. Primary Stress The three uni-directional tensile stresses oriented along the 3-D axes (see Right-Hand Rule) of a mechanical component Principal Planes(of a lens) The curved planes that trace the principal points of light-rays entering a lens parallel to its axis. The primary principal plane refers to the plane at the front of the lens The secondary principal plane refers to the plane at the back of the lens Principal Points(of a lens) The theoretical points of intersection of light-ray projections after entering and before exiting a lens. The primary principal points refers to those at the front of the lens The secondary principal points refers to those at the back of the lens see also Principal Planes and Nodal Points Principal Quantum Number(n) 'ε' The first in a set of numbers that uniquely describes the quantum state of an electron The principal quantum number of an electron can only be a positive integer and identifies the shell number it occupies: i.e. 1, 2, 3, 4, 5, 6, 7, etc. All other electrons in the same shell will have the same principal quantum number but at least one of its other quantum numbers must be different Principal Stress A primary stress reoriented (in space) and altered in magnitude as a result of simultaneous shear stresses Prism A longitudinal body with sides of equal width and constant cross-section. The term for a prism usually ends with '....hedron'. For example: Trihedron (3 sides) Quadrahedron (4 sides) Pentahedron (5 sides) Hexahedron (6 sides) Heptahedron (7 sides) Octahedron (8 sides) Nonahedron (9 sides) Decahedron (10 sides) Hendahedron (11 sides) Dodecahedron (12 sides) etc. Cylinder (∞ sides) Process(thermodynamics) Any alteration in the energy of a system Any change in the physical properties of a system will require a change in its energy, either by addition or removal and the physical properties of a system include: temperature; pressure; volume; dimensions; state (gas-liquid-solid); force; movement; etc. Reversible Process: One in which both the system and its surroundings can be returned to their original states with or without the addition of more energy. There will be no loss in the ability of a system to do work if the process is reversible. Irreversible Process: One in which neither the system nor its surroundings can be returned to its original state with or without the addition of more energy. There will be a loss in the ability of a system to do work if the process is irreversible. Prograde(rotation) The same direction of rotation as the spin (rotation) of a force centre For example, the sun in our solar system spins in a clockwise direction looking down on top of it All the planets orbitting and/or spinning in a clockwise direction are said to orbit and/or rotate in a prograde direction see also Sidereal and Retrograde Proton {© 01/10/18} A single indivisible packet of electro-magnetic charge that possess no intrinsic kinetic energy. All protons are identical. A lone proton is common hydrogen (H⁺). When partnered with an orbiting electron, the pair become an hydrogen atom (H). Its magnetic charge is non-polar and constant. Its electrical charge (eꞌ) is identical to that of an electron (e) when alone (not partnered) ... ... but positive and variable when partnered:eꞌ = mₚ.RC.√[Ṯ/Ṯₙ] ... the maximum (neutronic) electrical charge that can be held by a proton is defined thus:eₙ = mₚ.RC = 2.941838200933640E-16. mass; mₚ = 1.67262163783E-27 kg radius; rₚ = 1.77613270336827E-15 m see The Proton-Electron Pair see also Neutron Proton-Electron Pair {© 01/10/18} A proton with an orbiting electron. Attraction between the two particles is due to their opposite electrical charges. Velocity of the electron is due to electro-magnetic energy absorbed. see The Proton-Electron Pair see also neutron and electron PVRT Reference to a universally established calculation method for the properties of gases; p.V = n.Rᵢ.Ṯ Where: p = pressure V = volume n = number of moles Rᵢ = ideal gas constant Ṯ = temperature see also Thermodynamics Pyramid A regular or irregular three-dimensional prism or cone with a pointed cap see also Frustum Quadrangle An irregularly shaped four sided figure (see Quadrilateral) Quadrilateral A regularly shaped four sided figure CalQlata consider all quadrilaterals to be four-sided figures with all internal angles equal to 90° (see Quadrangle) Quanta A collection of more than one particle Quantum Number 'ε' One of a set of numbers that uniquely describe the quantum state of an electron The numbers are integers or half integers and positive or negative The numbers include; principal (n), azimuthal (ℓ), magnetic (m) and spin (s) Quark 'ε' The family of sub-atomic particles within the fermion group that constitute the constituents of matter Quarks combine to form composite particles called hadrons, the most well-known of which are protons and neutrons There are 6 quarks: up, down, charm, strange, top & bottom Quench The rapid cooling of a heated steel alloy to lock in an unnatural crystal structure to harden and strengthen it. Cooling may be carried out by liquids, solids or gases. Radial At right-angles to a central axis Radial Stress Primary stress at right-angles to (out-of-plane with) both longitudinal and lateral (or hoop) stresses Radian An angle expressed in terms of π π radians = 180° any angle 'A°' expressed in radians = A x π ÷ 180 Radiation(r) The emittance of electro-magnetic energy from a proton-electron pair. Radiation emittance is measured in Roentgens(J/kg or C/kg {Coulombs per kilogram} @ 1 Volt) 1 Roentgen corresponds to the production of1.61E+15 ion pairs/kg or 8.38E-03 J/kg {8.38E-03 C/kg} CalQlata has discovered a radiation constant that it has yet to explain: Newton's gravitational constant ÷ Coulomb's constant: √[G/k] = 8.61706029887133E-11 C/kg Radical A number multiplied by itself (as many times as you wish) e.g. in; 5x5x5; '5' is the radical (125 is its radicand) Radicand A number within a root e.g. in; ³√; 125 is the radicand (5 is its radical) Radioactivity The product of changing one isotope into another isotope i.e. when atoms lose or gain neutrons (alpha & beta particles) or the emission of electro magnetic energy (gamma) Radio Waves Very long-wave electromagnetic radiation used for the transmission of sound λ > 0.1m (ʄ < 2.99792459E+08Hz) Radius of Gyration(ɍ) The distance from an axis of rotation to the centre of area (or mass) ɍ = √(I/A) and ɍ = √(I/m) where: I = second moment of area A = area of section m = mass Ratio of Specific Heats(γ) γ = cp ÷ cv pure monatomic gases: γ ≈ 1.67 pure diatomic gases: γ ≈ 1.4 pure triatomic gases: γ ≈ 1.28 polyatomic gases (i.e. mixture of monatomic, diatomic and triatomic atoms): 1.0 < γ < 1.67 air: γ = 1.34213819 see Heat see also Specific Heat(s) Reactance (electrical) Reactance ('X') of inductance ('L') or capacitance ('C') is their resistance equivalent in an AC current. where: X = 2.π.ƒ.L (inductance) and X = 1/(2.π.ƒ.C) (conductance) ƒ = frequency Recrystallisation The movement of atoms in a metal lattice structure towards a low energy position. After cold working or heat treatment, a residual stress is generated in a metal by atoms having been forced away from their natural position within the lattice structure. Annealing allows these atoms to move back to their natural position in the lattice structure relieving internal stresses. Rectangle A two-dimensional, four-sided figure, each side of which is 90° to its adjacent sides see also Oblong Refractive Index The ratio of the phase velocity of electromagnetic radiation in a vacuum and its phase velocity in a medium For example: the phase velocity of light in air is 1.00292 slower than in a vacuum so the refractive index of air is 1.00292 and the phase velocity of light in water is 1.3333 slower than in a vacuum so the refractive index of water is 1.3333 see also Snell's Law Refraction The bending of light (or any electromagnetic wave) by altering its velocity; e,g, as it passes between media of different densities. see also Refractive Index Regular Lay A particular type of helical lay pattern in a wire rope where the filaments are wrapped within each strand in the opposite helical direction as the strands are wrapped within the wire rope. In a manufactured wire rope, the filaments run parallel with the long axis of the wire rope (see image). You can have 'right lay' or 'left lay' configurations: In a 'right lay' configuration the strands follow the same helical direction as a right-hand screw thread(see image) In a 'left lay' configuration the strands follow the same helical direction as a left-hand screw thread(opposite to image) Whilst these wire ropes provide less wear resistance than 'Lang lay' constructions due to their undulating (peaky) surface and lower bending fatigue resistance, the structure is much more stable and resistant to abuse. Regular lay wire ropes are generally used for all non-specialist applications. see also Lang Lay Relative Atomic Charge(RAC) The mol-charge capacity of sub-atomic particles:RAC = 96485.3317942156 C/mol (Faraday's Constant) Charge rate: q = RAC/RAM {C/mol x mol/g = C/g} electron: qₑ = 1.75881869180547E+08 C/g proton: qᵨ = 3.22945696453593E+11 C/g It is currently held that the proton carries the same charge as an electron as shown above, but CalQlata disagrees. CalQlata believes the charge rate of 1.7588187E+08 C/g is common to all atomic particles and that the charge between any two attracting particles is that of the lower. The remainder of the proton's higher charge capacity is therefore available to trap further electrons or neutrons. I.e. an electron carries a charge of 1.60217649E-19C and a proton carries a charge of 2.94183820E-16C Relative Atomic Mass(RAM) The mass number of the most stable isotope of an element the RAM of an element is also its specific mass in grams per mole (g/mol) For example, if Iron (Fe), which has an atomic number of 26, had the same number of protons and neutrons, its RAM would be 52 yet its actual value is 55.847. This means that in its most stable condition Iron's atoms contain more neutrons that protons and that this excess varies in any bulk of its material. electron: RAMₑ = 0.000548580318390698 g/mol proton: RAMᵨ = 1.00727638277233 g/mol neutron: RAMn = 1.00727638277233 g/mol 'Elements' calculates RAM values for all molecules Relative Charge (capacity)(RC) The electrical charge capacity of matter: RC = 1.75881869180547E+11 C/kg Reluctance(magnetisim)(S) The resistance in a material to permeate magnetic flux through a magnetic circuit. It is the magnetic equivalent of electrical resistance. The reciprocal of magnetic permeance (1/P) Resistance(electrical)(R) The static resistance (the unit of measurement is the Ohm) in a conductor due to its material resistivity, its cross-sectional area, its length and its temperature. The pipeline analogy for resistance is an internal restriction such as a helical vane or venturi both of which restrict flow but provide work and generates the pressure drop across the inlet and outlet of the pipe. R = V/I where: I = current and V = voltage Electrical resistance is directly proportional to the length of a conductor, and inversely proportional to its cross-sectional area. Resistor A material that prevents movement of its electrons when exposed to a potential difference This term is relative (see Conductor). You can have a good resistor and a bad resistor. The better the resistor, the harder it is for its electrons to flow Resonance(vibration) A vibration that occurs in a sprung system at or close to its natural frequency during which deflections are amplified Response Amplitude(vessels)(RA) The amount of movement in a vessel at sea (linear and rotary) generated by a passing hydrodynamic wave in six degrees of freedom Linear movement is measured in units of length (m, ft, etc.) &rotary movement is measured in angular units (° or rads) see also Heave, Surge, Sway, Pitch, Roll and Yaw Response Amplitude Operator(vessels)(RAO) A factor that must be multiplied by a wave height or slope (wave or water) in order to define a resposnse amplitude Linear movement is measured in lengths per unit length(m/m, ft/ft, etc.) &rotary movement is measured angles per unit length or angle(°/m, °/°, rads/rad,etc.) Also called a 'transfer function', which refers to the transfer of motion in a specified wave to the motion of the body (e.g. ship) Rest Mass The mass of a stationary body i.e., a body with zero linear and angular velocity Retrograde(rotation) The opposte direction of rotation as the spin (rotation) of a force centre For example, the sun in our solar system spins in a clockwise direction looking down on top of it All the planets orbitting and/or spinning in an anti-clockwise direction are said to orbit and/or rotate in a retrograde direction see also Sidereal and Prograde Rhombic Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain eight closely packed atoms, each of which are located at each corner of a cube that has slipped to form a rhomboid prism. Right-Angle An angle of exactly 90° Right-Hand Rule The thumb, index and middle fingers of the right hand are projected at 90° to each other in three dimensions, where the index finger represents the x-axis (Surge), the middle finger represents the y-axis (Sway) and the thumb represents the z-axis (Heave) This definition also refers to the direction of rotational twist about the vector axes; the thumb of the right hand is projected in the direction of the axes defined above and the four fingers naturally curled in towards the palm of the hand. The positive direction of rotation {xy(Yaw), xz(Pitch), yz(Roll} are in the direction of the four fingers Right-Angle Triangle A triangle with one of its angles at exactly 90° Roentgen [Röntgen](R) The unit of radiation exposure, dedicated to the discoverer of x-rays (Wilhelm C Röntgen). The exposure to 1 Roentgen is equal to the absorption of0.00838 J/kg Also described as the charge per unit mass (of air), equal to 2.58E-04 C/kg, generated by ionisation from x or γ-radiation Roll (vessels) The rotational movement of a vessel about the longitudinal ('x') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Rotational Acceleration(a) The equivalent linear acceleration of a point orbiting its force-centre (i.e. assuming the orbital path to be straightened out) see also Linear Acceleration and Angular Acceleration Rotational Velocity(v) Rotor The rotating part of an armature in a motor, alternator or generator. see also stator Rydberg Formula& Constants Johannes Rydberg developed his formula to calculate the wavelength of a photon that would be emitted when an electron drops from a high initial energy state (shell nᵒ: n₁) to a low final energy state (shell nᵒ: n₂), which can be calculated thus: λ = 1 / R∞.Z²(1/n₁² - 1/n₂²) Rydberg's universal constants for the limiting conditions are provided below: Maximum wave number: R∞ = mₑ.e⁴ / 8.ε₀².h³.c = 1 / aₒ.ξᵥ = 1.09737269561359E+07 /m (also minimum wavelength) Electron energy at ground state: Rᵧ = R∞.h.c.(Z/n)² = 2.17987197684936E-18 J which can be converted to eV thus: Rᵧ = Rᵧ/e = 13.605691968492 eV Where: R∞ = Rydberg constant (above) mₑ = electron mass mp = mass of protons in nucleus e = elementary charge unit ε₀ = permittivity of free-space h = planck's constant c = speed of light in a vacuum Z = atomic number n = electron number (1, 2, 3, etc.) Nils Bohr developed alternative values for R∞ and Rᵧ based upon reduced mass; mₑ/(1 + mₑ/mp): R = R∞ / (1+mₑ/mp) = 1.0967753777734E+07 /m R = Rᵧ / (1+mₑ/mp) = 2.1786854190384E-18 J Rydberg radius (orbital): aₒ = Rn.(ξv /4π)² = 5.2917721067E-11 m incorrectly referred to as the Bohr radius Safety Factor The proportion of additional stress (or use) that can be applied to a material (or component) before it fails. For example: if you design a component to experience less than or equal to 200 N/m² of stress and the material from which it has been manufactured has a minimum specified yield stress of 400 N/m², the component has a safety factor of 2 Safety factor is the inverse of utilisation Satellite A mass orbiting a force centre under the influence of gravitational force. For example: The earth is a satellite of the sun Our Moon is a satellite of the earth Saturation(fluids) The ability of a fluid to hold another substance (gas, liquid or solid) in suspension that varies with pressure and temperature High temperatures low pressures raise the saturation level Scalar(quantity) A quantity (magnitude) that has no direction, such as; volume, density, area, etc. see also Vector Schwarzschildradius(Rs) Karl Schwarzschild's formula to determine the radius of a mass that would prevent the escape of photons from its surface: Rs = 2.Gravitational constant.m/c² where: m = mass of the star Concerning the outer radius (R) of any given mass; if R > Rs light will escape its surface if R ≤ Rs light will not escape its surface Schwarzschild derived his formula from Newton's formula for escape velocity: v² = 2.G.m/R Schwarzschild's radius for any mass of ultimate density: Rs = c.√[³/₈ / π.G.ρᵤ] = 47494.1512680647 m Whilst his formula is correct, it applies to only to the fictitious photon. Seafastening Welds, padeyes, lugs and other deck attachment facilities used to fix a mass to any part of a ship or vessel in order to prevent unwanted movement whilst in transit at sea Seastate The properties of a sequence of following waves defining representative conditions used for equipment design and/or operational conditions. Seastates are usually compiled from actual data collected from anchored 'buoys' installed in various regions around the world and subsequently sorted seasonally, monthly or daily. Representative seastates are used for operational, design (e.g. fatigue calculations), extreme, etc. wave sequences for specified weather windows. Second Moment of Area(I) Describes the structural strength of a cross-sectional area, or a numerical representation of its resistance to bending deformation see also Moment of Inertia and Polar Moment of Inertia Section Modulus(Z) Describes the ratio of the second moment of area to the distance from the neutral axis of the stressed plane (I/y) Sector A shape enclosed by two radii and an arc of the same circle Segment A shape enclosed by a chord and an arc of the same circle Self-Holding When referring to Tapers (Morse, Jarno, Brown & Sharpe, etc.), "Self-holding" describes a condition whereby the assembly (insertion) force is the same as the disassembly (extraction) force and the coefficient of friction between tapered shaft and mating sleeve materials holds them together during use. Shatter Break apart (usually into small pieces) without deformation. Shear Angle(α) The angle between two parallel planes and two opposing forces. Shear Force Equal and opposite tangential forces induced in a substance between two parallel planes. Shear Modulus (G) Shear Stress(τ) Stress induced in a substance due to a shear force and a shear angle. τ = F / A.Sin(α) where 'A' is the area through the body as shown in the image. Sidreal(rotation) The actual rotation of a body, e.g. a planet, with respect to a fixed point in space This is not the same as the rotation of an orbiting body with respect to its force centre A planet rotating in the same direction as its orbit will have a shorter rotation [period] with respect to its sun than its sidereal rotation [period] A planet rotating in the oposite direction as its orbit will have a longer rotation [period] with respect to its sun than its sidereal rotation [period] see also Prograde and Retrograde Simple Support A support that prevents only one degree of freedom, which is at right-angles to the load Simpson's Rule An algebraic solution for integrals that are dificult or impossible to solve by integration Single-Phase(fluid flow) The flow of a single category of fluid. Normally applied to the flow of fluids through a pipe in the petroleum industry; where a single-phase fluid comprises ≈100%: Oil or water or gas. see also Multi-Phase Sinter The coalescing (conglomeration) of solid particles using heat but without actually melting (liquifying) the material. Sinusoidal A continuous curve with the same x,y relationship as the Sine of an angle Slag The unwanted (remnant) material left over after extracting a material from an ore. Slag contains commercially valueless material and an amalgamation flux. Slugging The thickening or solidification of a heavy liquid in a pipe or constricted passage that prevents free-flow conditions. Smelt The extraction of a metal from an ore by melting. During melting, the ore will seperate into two layers: a lower layer of molten metal and an upper layer of slag. S-N Curve The graphical representation (normally a straight-line Log10-Log10 plot) of maximum allowable stress range plotted against the maximum possible number of cycles (for this stress range), above which, damage to the material or mechanical component is expected (S-N = stress number, i.e. the number of stress cycles) Snell's Law Willebrord Snellius: Dutch Proffessor of mathematics at the University of Leiden Snell's law (1621) states that after passing from one medium of refractive index 'n₁' into a medium of refractive index 'n₂' a ray of light will refract according to the following relationship: n₁.Sin(θ₁) = n₂.Sin(θ₂) Solid Matter in a viscous state such that inter-atomic strength is sufficient to resist gravitational forces. This is a low temperature condition. Solidity is a relative term, it describes the ability of viscous matter to resist shear forces; or lattice plane slip. Solid state refers to high viscosity. # see State of Matter see also Liquid and Gas Solubility The ability of one substance (the solute) to dissolve onto another substance (the solvent) This ability may be measured in terms of moles per cube (e.g. moles/cm³) Sonic Refers to a condition that generates a sound. This condition varies with the properties (density, temperature, RAM, pressure, moisture, etc.) of the medium concerned #; e.g. the instant the velocity of an object travelling through air exceeds (overtakes) the velocity of the pressure wave it is generating in front of it. The speed of sound in gases is generally calculated today as follows: vₛ = √[γ.R.Ṯ] # where R = Rᵢ/RAM (kg/mol); Ṯ in (K) Whilst this velocity varies with altitude (depth), the speed of sound is generally quoted as; air; ≈340 m/s; ≈760 mph ≈661 knots; ≈1224 km/h # water; 1410 m/s; 3154.1 mph 2740.82 knots; 5076 km/h seawater; 1540 m/s; 3444.9 mph 2993.5 knots; 5544 km/h # see Speed of Sound see also Hypersonic, Subsonic, Supersonic, Transonic Sound(speed of) Refer to Sonic. Spar A principal structural member of an aircraft wing or aerofoil Special Relativity 'ε' A theory based upon the deformation of time that redefines the speed of objects moving close to the speed of light as: v = v / √[ 1 + (v/c)² ] based upon the misunderstanding that mass changes to energy with increasing velocity. see Relativity is Dead see also General Relativity Specific Charge(s) Two values are normally used, dependent upon the process (constant pressure or constant volume): qᵥ is the specific charge capacity of a charged particle under the conditions of constant volume qᵨ is the specific charge capacity of a charged particle under the conditions of constant pressure see also Charge Density and Specific Charge Capacity Specific Charge Capacity(qᵨ and qᵥ) The quantity of electrical energy that can be absorbed by a specific substance per unit charge (Coulomb), which does not vary with temperature The units of measurement are J/C, ft-lb/C, Btu/C, etc. Specific charge capacity of atomic particles: electron: qᵥ = 1.282566468949240E-04 J/C/K Qᵥ = 2.054897840244850E-23 J/K qᵨ = 2.137610781582070E-04 J/C/K Qᵨ = 3.424829733741420E-23 J/K lone proton: qᵥ = 6.98508109518973E-08 J/C/K Qᵥ = 2.05489784E-23 J/K qᵨ = 1.164180182531620E-07 J/C/K Qᵨ = 3.42482973E-23 J/K see also Specific Charge(s) and Charge Capacity Specific Enthalpy(h)(thermodynamics) The enthalpy per unit mass of a system h = u + Rₐ.Ṯ where; u = specific internal energy Rₐ = gas constant Ṯ = temperature (absolute) The units of measurement are J/g, Btu/lb, etc. see Heat Specific Entropy(s)(thermodynamics) The entropy per unit mass of a system s = KB.ln(N) = cp.ln(Ṯ) {per molecule} s = KB.NA.ln(N) = cp.ln(Ṯ) {per mole} s = KB.NA.ln(N)/RAM = cp.ln(Ṯ)/RAM {per unit mass} Where; KB = Boltzmann's constant NA = Avogadro's number N = number of microstates cp = specific heat capacity (constant pressure) RAM = relative atomic mass Ṯ = temperature (absolute) The units of measurement are J/K/mol or J/K/g, Btu/°R/lb-mol or Btu/°R/lb, etc. see Heat and Thermodynamics Specific Gravity(SG) Also called 'Relative density', is the density of a liquid or a solid relative to pure water (1000 kg/m³). For example, the SG of steel is 7.85 (7850 kg/m³ divided by 1000 kg/m³) The specific gravity of a gas is quoted relative to the density of air (1.297 kg/m³). For example, the SG of helium is 0.1365 (0.177 kg/m³ ÷ 1.297 kg/m³) Specific Heat(s) Two values are used in thermodynamic calculations, dependent upon the process (constant pressure or constant volume): cᵨ is the specific heat capacity of a gas that is heated and allowed to expand whilst maintaining at constant pressure cᵥ is the specific heat capacity of a gas that is heated in an unchanging volume but where pressure is allowed to vary Specific Heat Capacity(cᵥ and cᵨ) The quantity of heat energy that can be absorbed by a specific substance per unit mass, which does not vary with temperature. The most common units of measurement are J/kg/K, W.s/kg/K, BTu/lb/R, etc. Specific heat capacity of dry air: cᵨ = 965.4 J/kg/K (constant volume) cᵥ = 719.3 J/kg/K (constant pressure) see State of Matter see also Specific Heat(s), Specific Heat Ratio and Heat Specific Heat Ratio(γ) The ratio of specific heat capacities: γ = cᵨ:cᵥ see State of Matter see also Specific Heat(s), Specific Heat Capacity and Heat Specific Internal Energy(u) The internal energy per unit mass of a system u = Ṯ.cᵥ where; Ṯ = temperature (absolute) cᵥ = specific heat capacity (constant volume) The units of measurement are J/kg, Btu/lb, etc. see Thermodynamics see also Heat Specific Volume Volume per unit mass, or... the reciprocal of density Specified Minimum Yield Stress(SMYS) The minimum yield strength (maximum allowable yield stress) for a material as specified by a recognised authority Spheroidising(annealing) The balling up of the cementite in pearlite during the annealing process Carbon steel must be held below the lower critical temperature (723°C), ensuring no phase change takes place, allowing sufficient time for the large globules of cementite to break up into small globules and redistribute evenly Spin Energy The energy generated by a rotating body of a specific polar moment of inertia: E = ½.J.ω² Note: 'ω' is measures in radians per second. Spin Quantum Number(s) 'ε' The fourth in a set of quantum numbers that describes the spin direction of the electron The spin quantum number of an electron can be a positive or negative half integer: i.e. -½ or +½ The spin quantum number must be different for each electron in the same shell with the same azimuthal and magnetic quantum numbers Spring Coefficient(k) The proportional relationship between force and movement for an elastic material or a spring i.e. the amount of force required to deform a material or a spring per unit length Also referred to as a spring constant and spring rate Measured in e.g. N/m (lbf/in) see also Stiffness Spring Constant(k) Sprung System Any machine or structure, or part thereof, that obeys Hooke's Law, which includes most metals, elastomers (rubber), ceramics, hard-woods, etc. Spur Gear A gear wheel, with teeth cut into its circumference at 90° to the plane of the wheel, that normally (but not necessarily) mates with another spur gear Also referred to as straight-cut gear The centres of rotation of two mating spur gear wheels are always parallel Stanchion A vertical structural member Station-Keeping(orbits) {© 05/03/16} A satellite's ability to maintain its orbital path; whilst resisting the gravitational effects of other celestial bodies passing close-by. Stator The stationary part of an armature in a motor, alternator or generator. see also rotor Steady Flow(thermodynamics) A fluid flowing through a system the conditions and properties of which do not change with time. Stiction Stiction (static friction) is the resistance to initiate relative movement between two surfaces when forced together Stiction is always greater than friction Stiffness The resistance any material or structure exhibits to deformation Stiffness can be applied to bending, torsional and axial deformaton and describes the rate of dimensional change for a specified force see also Spring Coefficient Strain(e) The elongation in a material as a result of stress see also Elastic Strain and Plastic Strain Strand(wire rope) More than one filament wound together see also Wire Rope Strange Quark 'ε' The third lightest of all the quarks and part of the second generation of matter The strange quark is classified as a fermion mᵣ=1.693528659E−25g [95.0MeV/c²], Q=-⅓e, Iz=-½ Stratosphere The ceiling for 99% of nitrogen, the earth's most abundant atmospheric gas Altitude @ equator: 15km to 60km Altitude @ poles: 10km to 50km Stratum of the earth's atmosphere that comprises mainly nitrogen and oxygen and is considered to be the upper limit of the atmosphere that contains anything of substance Temperature increases with increasing altitude Stress(σ, s) Force per unit area [in a substance]. (similar condition to pressure and defined using the same units; e.g. N/mm² or lbf/in²) Stress in a viscous body is actually the resistance to magnetic attraction between its adjacent atom (and or molecule). the general formula for this property is; σ = F ÷ A where A is the area over which 'F' is applied Tensile stress: induced in a material as a result of a positive axial load Compressive stress: induced in a material as a result of a negative axial load Shear stress: induced in a material as a result of a shearing (or tearing) action or induced as a result of more than one primary stress Bending stress: induced in a material as a result of bending - tensile stress at the outside of the bend, compressive stress at the inside of the bend, zero stress at the neutral axis Failure in materials due to elastic stress is predicted using various theories: Principal stress (Rankine), Principal strain (e.g. St Venant) or strain energy (Beltrami and Haigh), shear (e.g. Tresca) or shear strain energy (Henckey & Von Mises) Stress Amplitude (Sa) Half the stress range (Sa = δS÷2) Stress Block A collection of characteristic identical stress ranges that represent a defined period of time in the fatigue life of a material or component Stress Corrosion Cracking The cracking or 'crazing' of a metal surface due to galvanic corrosion whereby the cracks generate stress-concentrations in the material weaking its ability to deform elastically Hydrogen emrittlement is a typical example of this problem (see Cathodic Protection) NACE MR0175/ISO 151546-1:2001(E) are internationally recognised standards that offer advice as to the control of this problem Stress Cycle One stress cycle is twice the stress range (e.g. maximum to minimum and back to maximum again) Stress (mean) Middle of the the stress range (Sm = (Ṡ+Ṣ)÷2) Stress Range(δS) The difference between the maximum stress and the minimum stress in a single stress cycle (δS = Ṡ-Ṣ) Subduction The passing of planet's crust under a tectonic plate and down into its mantle Regions where this occurs are called Subduction Zones, and they are usually active with volcanoes and earthquakes Subsonic Refers to a velocity less than Sonic. see also Hypersonic, Supersonic, Transonic Substance The bulk quantity of particles in a viscous state. see also Matter (the) Sun Diameter: 1.3914E+06 km Surface area: 6.0821E+12 km² Volume: 1.41044E+18 km³ Mass: 1.9885E+30 kg Density (average): 1409.8437 kg/m³ Luminosity: 382.8E+24 J/s Surface emission: 6.294E+07 J/m²/s Surface temperature: 4400 K Effective temperature: 5772 K Core temperature: 1.571E+07 K Principal constituent elements (99.998%): Hydrogen: 90.965% Helium: 8.889% Oxygen: 0.0774% Carbon: 0.0330% Neon: 0.0112% Nitrogen: 0.0102% Iron: 0.0043% Magnesium: 0.0035% Silicon: 0.0032% Sulphur: 0.0015% The above figures are provided in NASA's Sun Fact Sheet Supersonic Refers to a velocity greater than Sonic. see also Hypersonic, Subsonic, Transonic Surface Energy(US) The free energy per unit area in a substance US = surface tension x surface area the units of measurement are J, Btu, N.m, lbf.ft, etc Surface Tension A property of liquids whereby their surface appears to have an elastic membrane in a state of tension the units of measurement are N/m, dyne/cm, lbf/ft, etc This phenomenon occurs at the surface of liquids due to unbalanced cohesive forces between surface molecules that do not occur in the bulk of the liquid where molecular cohesive forces are able to act in all directions. Surge (vessels) The linear movement of a vessel in the direction of the longitudinal ('x') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Sway (vessels) The linear movement of a vessel in the direction of the lateral ('y') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Sweating(metals together) Line (or coat) the surfaces of two metals with melted solder or braze and allow to cool. Subsequently press the two metals together whilst heating to a temperature sufficient to remelt the solder or braze. Then allow to cool whilst under pressure. System Thermodynamic: A quantity of matter subjected to a process, everthing else is its surroundings For example when evaluating steam in an autoclave, everything apart from the steam itself is its surroundings (including the pressure vessel and its environment) Mechanical: The components that together create a particular action For example a bicycle comprises the frame, wheels, chain and drive mechanism, brakes, handlebars and seat. Everything else (mudguards, paniers, basket, etc.) is an accessory. Chemical: The molecules, atoms, sub-atomic particles and electro-magnetic radiation that are responsible for a chemical reaction For example an oxygen atom (O), an oxygen molecule (O₂) and UV light that together create Ozone (O₃) Tangential Velocity(vT) The instantaneous linear velocity of an orbital particle or satellite, which may be calculated as follows: vT = ω.R where: 'ω' is the angular velocity of the particle or satellite 'R' is the orbital radius Tauon 'ε' A negatively charged elementary particle also referred to as a tau particle The tauon and its anti-particle carry the same electric charges as the electron and positron respectively A tauon is classified as a lepton m=3.167469045E-24g [1.77682GeV/c²], lifetime≈2.9E-13s Tectonic Plate An area of planet crust that changes size and shape over time due to mantle activity Normally, a length of the tectonic plate's perimeter (edge) grows through new rock generation from volcanic emissions and the remaining perimeter is subject to subduction Temper Tempering is carried out to increase toughness and ductility in a material that has been previously hardened. The tempering process is carried out by heating the material to a temperature below its transformation temperature (1330°F or 723°C) and cooling in a controlled environment/manner to allow some recrystallisation to occur. E.g. for carbon steel, the tempering range is 210°F (100°C) to 1200°F (650°C). The higher the tempering temperature, the greater the toughness and the lower the resultant hardness and strength. Temperature(Ṯ) The heat energy in electro-magnetic energy. The temperature we measure, is the temperature of an atom's innermost atomic shell (Shell 1). The degree of heat measured relative a particular scalee.g. triple-point of fresh water and absolute zero The two most commonly used 'absolute' scales are: Kelvin (K):0K is absolute zero and the triple-point of water is 273.15K Rankine (°R):0°R is absolute zero and the triple-point of water is 491.67°R 1°R = 5/9K The two most commonly used 'non-absolute' scales are: Celsius; also called centigrade (°C):0°C is the triple-point of water and the boiling point of water at 1 atmosphere = 100°C Fahrenheit (°F):32°F is the triple-point of water and the boiling point of water at 1 atmosphere = 212°F 1°F = 5/9 x 1°C To convert between scales: X°F = Y°C x 9/5 + 32 Y°C = 5/9 x (X°F - 32) 0K = 0°R = -273.15°C = -459.67°F 255.37K = 459.67°R = -17.78°C = 0°F 273.15K = 491.67°R = 0°C = 32°F The lowest possible temperature in the universe (2.04274907568265K) is the basic temperature. The lowest temperature in the universe is that of outer space (2.7255K), which is all the EME radiated by all of its stars and its planets. The highest possible temperature in the universe (623316124.717178K) is the neutronic temperature. Temperature Constant(K) {© 30/10/22} Temperature constant used to define electrical force between adjacent atoms: K = √[Ṯₓ/Ṯₙ] electrical forceFₑ = K.mₚ.v²/Rₛ where: v = electron orbital velocity Rₛ = atomic spacing. Tensile Modulus A general term that applies collectively to the resistance to axial deformation for all materials (e.g. metals, polymers, woods, etc.) including; Young's, flexural and elastic moduli. Tetra-hedra Describes the lattice arrangement of atoms within a metal. The smallest crystal of this metal will contain four closely packed atoms, each of which are located at each corner of a tetrahedron. Thermal Conductivity(k) The rate at which heat flows through a material or substance of unit thickness. Thermal Resistance(R) The temperature difference across a barrier of a specified thickness when a unit of heat flows through it in unit time. The reciprocal of 'Heat Transfer Coefficient'(R = 1/U) Thermodynamics The theory of the transfer of energy between systems or its conversion into work In other words ... 'it is the formulas and calculations used to identify the amount of heat energy that is transferred from one system to another or converted into mechanical, chemical or electrical action, and how much is lost to its surroundings, i.e. the efficiency of the process' Thermosphere Stratum of the earth's atmosphere that contains the Ionosphere (Lower Thermosphere) and the Exosphere (Upper Thermosphere) Thermosphere means 'hot region'. The temperature of this region increases exponentially with altitude but the density of material in this stratum is so thin that the heat generated cannot be readily transferred. Thin-Wall Tube A pipe or cylinder, the nominal radius (r) of which is greater than ten times its wall thickness (t). r/t > 10 In reality, this definition varies throughout industry, dependent upon the reference documentation, some of which are listed below: ASME VIII; Div. 1; rₒ/t ≥ 5 (1); r/t > 10 (2); rₒ/t > 5 (3); rₒ/t > 5 (4); r/t > 10 (7); r/t > 30 (75); rᵢ/t > 10 Where: rᵢ = inside radius; r = nominal radius; rₒ = outside radius. Through Harden A process whereby the entire body of a steel alloy is hardened to the same extent and is normally achieved by the addition of alloying elements. Top Quark 'ε' The most massive of all the quarks and part of the third generation of matter The top quark is classified as a fermion mᵣ=3.085252685E−22g [173.07GeV/c²], lifetime≈5E−25s, Q=⅔e, Iz=½ Torque A rotational moment This is a tangential force applied to a structural element at a given radial distance from the axis of twist. Torsion The act of applying a torque to induce stress or tighten a screw. Transfer Function(ships) Transformation Temperature The temperature range during which austenite occurs during heating. It is also a different temperature range during which Austenite disappears during cooling. These temperature ranges may overlap but they are never the same. Transformer (electrical) A transformer is a single central magnet around which are wound two or more separate copper wire coils with a different number of turns. One of the coils will be the input power supply and the other will be output power supply. Both supplies will have same power (Volts x Amps) if you ignore losses. The voltage in each coil will vary thus: V2 / V1 = n2 / n1 So the largest number of turns will have the highest voltage but lowest current and vice-versa. Transom An horizontal (or transverse) structural member Transonic Refers to a condition in which Subsonic and Supersonic flows are present. see also Hypersonic, Sonic, Triangle A two-dimensional, three-straight-sided closed shape the 3 angles of which add up to 180° (πᶜ) Triatomic (gas) A gas (mixture or pure) comprising only molecules three atoms, such as ozone, water vapour, carbon dioxide, nitrous oxide, etc. Triple-Point of Water 273.16K, 0.01°C, 32.018°F & 491.688°R The temperature at which pure water can exist in all of its phases (solid, liquid and gas) simultaneously at 1 atmosphere (pressure) Tritium (atom)(T) A proton-electron pair with two neutrons attached. see also Hydrogen and Deuterium Trochoid (curve) A trochoid is a curve generated by a point inside or outside the circumference of a circle that is rolled along a flat, straight surface. see also Cycloid, Epicycloid and Hypocycloid Troposphere The ceiling for 75% of nitrogen, the earth's most abundant atmospheric gas Altitude @ equator: 0km to 15km Altitude @ poles: 0km to 10km Weather generating stratum of the earth's atmosphere that contains all of the earth's gases Temperature reduces with increasing altitude True Power (electrical) True power is the apparent power multiplied by the power factor and is normally expressed in terms of 'W' or 'kW'. see also Alternating Current and Phase Angle Turbulent Flow A flowing fluid that disturbs and mixes adjacent layers Ultimate-Body {© 01/10/18} All the mass of the universe (4.7134117E+48 kg) combined through magnetism that was collectively responsible for the last The Big Bang and includes the body mass of the Great Attractor. The theoretical minimum mass required to create the 'Big-Bang' is 4.692E+48 kg see The Universe Ultimate Tensile Stress(UTS) The maximum stress a material will support before it begins to suffer internal fracturing Resistance to deformation (strength) is increased between yield stress and ultimate tensile stress through work hardening The gradual reduction in strength after reaching UTS is due to increasing internal fracturing which will continue to reduce until the material breaks Uncertainty Principle(Heisenberg) 'ε' Any pair of dimensional variables (e.g. time and energy) describing a sub-atomic particle cannot be determined to an accuracy whereby the product (multiplication) of the errors (of each variable) is less than Dirac's constant E.g.: the more precisely the position of a particle is determined the less precisely its momentum can be known, and vice-versa Universal Period {© 01/10/18} The period of time between successive Big-Bangs. Based upon a universal age of 13.5 billion years and an estimated velocity of Hades of 600,000m/s, our current universal period will be 64.6286363 billion years (between 'Big-Bangs'). see The Universe Upheaval Buckling (pipeline) Lateral displacement of a pipeline due to uncontrolled longitudinal compression. Up Quark 'ε' One of the two types of quark that make the proton and the neutron and forms part of the first generation of matter The up quark is classified as a fermion mᵣ=3.565323494E-27g [2.01MeV/c²], Q=⅔e, Iz=½ Utilisation The proportion of limiting stress (or use) you design into a component before its material fails. For example: if you design a component to experience a maximum design stress of 200 N/m² and the material from which it has been manufactured has a minimum specified yield stress of 400 N/m², the component has a utilisation of 0.5 Utilisation is the inverse of safety factor Vacuum A volume greater than zero that contains no matter; i.e. no atomic particles. Valence Shell(of an atom) 'ε' The outermost shell of an atom in which an electron exists and includes all sub-shells The valence shell represents an atom's bonding capacity and hence defines its chemical properties. Vapour A liquid in a gaseous state that exists below its critical temperature. This is the official version. In reality, a vapour is a collection of disparate molecular globules, i.e. a liquid, suspended in a gas. It doesn't become a gas until it reaches its critical temperature. The size of the liquid globule is dependent upon the surface tension of the liquid at the temperature and pressure of the gas in which it is suspended. Vector(V) A straight line action (e.g. force) that has both magnitude and direction see also Polar Co-Ordinates and Cartesian Co-Ordinates Velocity(v) Rate of change in distance. This value may be interpreted as the first derivative of the distance between two points in a journey, which may described mathematically thus: distance: s = u.t + ½.a.t² velocity: δs = u + a.t . δt example units for which are; m/s (metric) or ft/s (Imperial). where: s = distance u = initial velocity t = elapsed time for 's' Vertex (Vertices) The point at which one end of each of two lines connect Vibration The elastic reponse of a sprung system to repeated loads of similar magintude and frequency Virtual Mass(fluidics) A shape coefficient that represents the sum of the fluid displaced by the body and the added mass of the surrounding fluid dispursed by the body and its displaced mass also know as Inertia Coefficient Viscosity Viscosity is the measurement of a solid or liquid substance's resistance to shear, and therefore to flow. This is a low-temperature state, in which the magnetic attraction between adjacent atoms is greater than their electrical repulsion. Kinematic viscosity (ν) is measured in units of m²/s, although it is most commonly measured in Stokes (St) or centiStokes (cSt) where 1m²/s = 1000St It is interesting to note that the units for kinematic viscosity (m²/s or ft²/s) are the same as Isaac Newton's constant of motion. Dynamic (or absolute) viscosity (μ) is the kinematic viscosity multiplied by the mass density (ρ) of the fluid and has the units of kg/s/m (or N.s/m²), although it is more commonly measured in Poise (P) or centipoise (cP) where 1N.s/m² = 10P It is interesting to note that the units for dynamic viscosity (N . s/m² or slug . s/ft²) are the same as Isaac Newton's concept for force divided by his constant of motion. The mathematical relationship is as follows: μ = ν.ρ For example; because water (H₂O) has ten proton-electron pairs, its viscosity should be; ν = 10.(hₑ+hₚ) = 8.645116E-06 m²/s = 0.0008645116 cSt water apparently has a kinematic viscosity of about 0.001 cSt (determined by experimentation!). It appears that Newton had discovered the concept of viscosity 150-years before Poiseuille! Voltage(V) The potential difference between two sources of electrical energy (the unit of measurement is the Volt). Also known as potential difference (pd) and electro-motive force (emf) The pipeline analogy for voltage is the pressure drop across the inlet and outluet of a pipe with a fluid flowing through it. V = I.R also; 1 V = 1 J/C 1 eV = 1.60217648753E-19 J/C Vortex(fluidics) The rotary motion of a fluid, which may be free or forced. see Vortices Vortex Shedding The generation of 'vortices' (rotating fluid) in the wake of a fluid passing over an object Vorticity(fluidics)(ζ) A measure of the local angular [rotary] motion of a fluid in a vortex. Also defined as the curl or strength of a vortex Generally accepted as twice the angular rate of rotation of the vortex; 'ω' (radians per second) Anti-clockwise rotation is generally referred to as positive and clockwise rotation as negative. ζ = 2.ω is applicable to rotational vortices (see image) ζ = 0 is applicable to irrotational vortices (see image) W Boson 'ε' A weak force carrier There are two types of W Boson (one with an electric charge of +1e and the other with an electric charge of –1e) Wˉ is the anti-particle of W⁺ m=1.4332244E−22g [80.398GeV/c²], lifetime≈3E-25s, Q=±1e, Iz=1 Wave Celerity(c) The speed (or velocity) of a wave. Wave Frequency(ƒ) The reciprocal of the wave period. Wavelength(λ) The speed of a wave divided by its frequency Wave Number(k) The reciprocal of wavelength k = 2π/wavelength Wave Period(p) The time taken for a wave to travel through a full wavelength. Weak Force 'ε' An interaction between elementary particles that is responsible for certain decay processes (such as beta radiation) and acts upon all known fermions Particles interact through the weak force by exchanging W & Z Bosons, which are heavy (≈100 times that of a proton). Their mass defines the short-range (≈1E-17m or ≈100 times less than the diameter of a typical atomic nucleus) nature of the weak force and that makes the weak force appear weak at the low energies associated with radioactivity. Weather Window A period of time during which limiting weather conditions will not be exceeded i.e.; A large weather window means a long period of time over which these limiting conditions are not expected to be exceeded conversely; A small weather window means a short period of time over which these limiting conditions are not expected to be exceeded Weber(Wb) The unit of measurement for magnetic flux. 1 Wb = 1 V.s = 1 J/A Weight The resultant force between two bodies as a result of gravitational acceleration and is measured in N, pdl, etc. The weight of a body is equal to its mass multiplied by the gravitational acceleration. This property varies with gravitational acceleration. That is, any given mass will weigh differently on the Earth and the Moon, both of which have different gravitational accelerations. Out in deep space, away from all gravitational effects, a mass of 1 tonne will weigh nothing! Weld Joint Factor(WJF) A utilisation factor for the strength of a welded joint A weld joint factor of 1.0 is usual for coded welders using certified procedures and materials The lowest WJF for a weld completed by an experienced, but uncoded welder using uncertified procedures and materials is ≈0.6 WJFs less than this are normally associated with unreliable welds. Wire Rope A rope comprising at least one strand, which comprises more than one filament made from metal Also recognised generically as: wire, steel rope, multi-strand wire, flexible wire, cable, cord and steelcord Work A quantity synonymous with energy Mechanical: a force applied over a distance greater than zero Electrical: power (W, J/s) multiplied by the duration (seconds) Thermo-Chemical: specific heat capacity multiplied by the mass and multiplied by the temeprature of a system The greater the force or the further the distance the more work has been done The units of measurement are; Btu, W.h, J, cal, N.m, lbf.ft etc. Work Harden The process of through-hardening a steel or a steel alloy by repeated deformation at stresses greater than yield stress However, if the steel/alloy is subsequently held at a sufficiently high temperature for a long enough period it will eventually revert to its original properties Wrap(wire rope) The longitudinal helical coiling of filaments into strands or strands into wire rope during the manufacturing process see also Lang Lay and Regular Lay X-Rays Short-wave electromagnetic radiation that falls between ultra-violet light and gamma radiation Ranges from: 1.0E-10m<λ<1.0E-08m (3.0E+18Hz>ʄ>3.0E+16Hz) Yaw (vessels) The rotational movement of a vessel about the vertical ('z') axis Whilst this term generally applies to the movement of ships, it is also used to define the movement of any object subject to the same degrees of freedom; e.g. aircraft and spacecraft see Right-Hand Rule for positive and negative directions of this movement Yield Stress The maximum stress that can be applied to a metal whilst that continues to obey Hooke's Law The release of stress above yield stress will result in permanent deformation of the material see also Specified Minimum Yield Stress Young's Modulus(E) The linear relationship (the slope of the curve) between purely elastic stress and strain in a material i.e. a material that obeys Hooke's Law Z Boson 'ε' A weak force carrier There is one type of Z Boson, which only changes spin and momentum but cannot change either electric charge nor any other charges (like strangeness, charm, etc.), so it never changes the generation or flavour of the particle emitting it. The Z boson (or 'Z') is electrically neutral and is its own anti-particle m=1.62556647E−22g [91.1876GeV/c²], lifetime≈1E-25s, Q=0, Iz=1

'ε': Owing to the scientific work completed by Keith Dixon-Roche over recent years, CalQlata has concluded that a number of the conventional definitions [originally] provided above are little more than unsupported guesswork based upon flawed assumptions (e.g. light possesses mass). Whilst they remain in this webpage, they are now provided for information only.
